Поз.
Артикул
Описание
683
LINE FROM EXPANSION TANK TO WATER PUMP,6 900042
687
COOLING WATER PIPE FROM EXPANSION TANK TO WATER PUMP
688
HOSE FROM WATER PUMP TO EXPANSION TANK 28X37X80,5 022370 ORDER BY THE METER
689
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
689
CLAMP
690
SCREW PIPE CLAMP
690
SCREW , Replaced By: N304017008021
691
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
691
NUT , Replaced By: N913004008001
691
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
693
BRACKET , Replaced By: A3834929141
693
BRACKET COOLING WATER LINE TO FRAME
694
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
695
CLAMP COOLING WATER LINE TO FRAME
697
SCREW , Replaced By: N304017008034
697
SCREW BRACKET TO CROSS CONNECTION STRUT
697
SCREW , Replaced By: N304017008021
697
SCREW PIPE CLAMP
699
SCREW , Replaced By: N304017008016
699
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
699
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
701
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
701
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
701
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
701
NUT , Replaced By: N913004008001
703
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
704
CLAMP , Replaced By: N000000000667
704
CLAMP HOSE TO FITTING AND TO OIL TANK
704
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
704
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
705
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
706
CLAMP , Replaced By: N916017011001
706
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
707
COOLING WATER PIPE DE-AERATION, FROM FLANGE TO CONNECTION POINT
713
LINE FROM CONNECTION POINT TO EXPANSION TANK,6 900042
716
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
717
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
717
CLAMP , Replaced By: N000000000667
718
BRACKET DE-AERATION LINE TO SUPPORT,6 900042
719
BRACKET DE-AERATION LINE TO SUPPORT
720
BRACKET DE-AERATION LINE TO SUPPORT
722
SCREW PIPE CLAMP
722
SCREW , Replaced By: N304017008021
725
COOLING WATER PIPE (DE-AERATION LINE) FROM RADIATOR TO EXPANSION TANK
726
COOLING WATER PIPE FROM FRONT DE-AERATION LINE TO CONNECTION
727
COOLING WATER PIPE FROM FRONT DE-AERATION LINE TO CONNECTION,6 900042
730
HOSE DE-AERATION LINE, LENGTH AVAILABLE: 1000 MM
731
CLAMP , Replaced By: N916017011001
731
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
735
CLAMP , Replaced By: A3604300143
735
CLAMP , Replaced By: N916016008200
735
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
735
CLAMP ,K 147121, Replaced By: N000000000319
737
CLAMP , Replaced By: A6739950001
737
CLAMP DELIVERY AND SUCTION LINES TO STEERING
740
SCREW PUMP TO BRACKET
740
SCREW , Replaced By: N304017006016
744
NUT PUMP TO BRACKET
744
NUT , Replaced By: N913004006001
745
TANK EXPANSION TANK
746
RADIATOR CAP CENTRAL
746
RADIATOR CAP CENTRAL
747
RADIATOR CAP
748
RADIATOR CAP FILLER NECK
748
RADIATOR CAP FILLER NECK
749
GASKET O.D., 52 MM
750
GASKET O.D., 37 MM
754
CLAMP EXPANSION TANK TO SUPPORT
999
GASKET , Replaced By: A0011315380
999
GASKET
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 52 CCM,TO 000 205 58 06
999
HOSE , Replaced By: A0020945482
999
GASKET , Replaced By: A0011315280
999
RADIATOR WATER
999
RUBBER MOUNTING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6255000012, +002A6255004231, +002A6255041053, +004A3839900446, +002N000960014145, +004N000961012093
999
SCREW , Replaced By: A0019902120
999
SCREW PLUG , Replaced By: N007604014101
999
HOSE , Replaced By: A0010947982
999
SEAL RING , Replaced By: A0159972947
999
BALL BEARING , Replaced By: A0049810525
999
ALTERNATOR , Replaced By: A0071542702
999
BRACKET , Replaced By: A3974290140
999
CLAMPING PIECE , Replaced By: A4212060034
999
BRACKET , Replaced By: A3524290740
999
HOSE , Replaced By: A3635060235
999
BRACKET , Replaced By: A6205243040
999
GASKET , Replaced By: A4422010480
999
OIL LINE , Replaced By: A4231801420
999
BRACKET , Replaced By: A3013010084
999
FAN , Replaced By: A4232000123
999
TIGHTENER PULLEY
999
RUBBER BUFFER LOWER BRACKET TO OUTSIDE SUPPORT,6 900042
999
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6255004231, +002A6255000012, +002A6255041053, +004A3839900440, +002N000960014145, +004N000961012093
999
SUPPORT , Replaced By: A6255003227
999
SUPPORT , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6255004127
999
CONNECTOR , Replaced By: A6255010123
999
PIPE ELBOW , Replaced By: A6255010156
999
BUSHING , Replaced By: A4409910040
999
BRACKET COOLING WATER LINE TO BASE FRAME,6 900043
999
WASHER SPARE WHEEL CARRIER
999
BRACKET , Replaced By: A3184923441
999
BRACKET
999
BRACKET DEAERATOR LINE TO INTAKE MANIFOLD,6 900042
999
BRACKET
999
BRACKET , Replaced By: A3875010820
999
BRACKET COOLING WATER LINE TO CONVERTER LOCKUP COUPLING,RIGHT BOTTOM,6 900042
999
BRACKET , Replaced By: A3184924841
999
BRACKET DE-AERATION LINE,6 900042
999
BRACKET AIR DUCT,6 900042
999
BRACKET , Replaced By: A3875015820
999
BOOT , Replaced By: A6205050186
999
HOSE , Replaced By: A4969970082
