Mercedes A6278320323 - Шланг

5

VALVE

8

SOLENOID , FROM IDENT NO. 103042 ALSO INSTALLED ON 102603,102680,102700,102714,102727,102738,102754-102762,102766,102771-102774,102777-102781,102787- 102793,102809-102811,102816,102817,102819-102822,102824,102827-102829,102832-102835,102837-102840, 102842,102881,102882,102885-102893,102895,102896,102898,102899-102905,102907-102909,102911-102913, 102916-102918,102920,102921,102923,102925,102926,102928-102933,102937-102942,102944,102945,102947- 102951,102955-102959,102962-102967,102969,102970,102974-102982,102985,102986,102988-103012,103014- 103025,103027-103041.

12

HOSE LINE ON DELIVERY SIDE 14.9 MM

13

SEAL RING

15

PIPE LINE ON DELIVERY SIDE D10X1MM

18

HOSE LINE ON SUCTION SIDE 19.9 MM

19

SEAL RING

20

SEAL RING

21

PIPE LINE ON SUCTION SIDE

68

ADAPTER REFRIGERANT LINE TO BRACKET

69

CLAMP SAFETY VALVE AT BRACKET

69

CLAMP OIL LINE TO BRACKET

69

CLAMP22/15

69

CLAMP LINE MOUNTING

69

CLAMP CABLE HARNESS MOUNTING

69

CLAMP BRAKE HOSE BRACKET

69

CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE

69

CLAMP PIPE ON FAN SHROUD

999

COOLANT LINE LOW PRESSURE 550MM

999

SWITCH LOW PRESSURE 0,2/0,4BAR

999

SWITCH HIGH PRESSURE 18/22BAR

999

GASKET34X42 MM

999

LOOM TIE LINE MOUNTING

999

GROMMET 34 MM

999

999

999

999

999

PIPE LINE ABOVE REAR AXLE, DIA., 12X1 MM

999

PIPE LINED10X1MM

999

PIPE LINED10X1MM

999

999

999

999

999

999

999

HOSE HIGH PRESSURE 370MM

999

999

PIPE LINE ON DELIVERY SIDE D10X1MM

999
