Поз.
Артикул
Описание
54
T-FITTING
57
INTERMEDIATE PIECE FROM T-FITTING TO CHECK VALVE
60
VALVE (BALL COCK)
63
SEAL RING BALL COCK
66
FITTING BALL COCK,089991
69
LINE FROM BALL COCK TO FILLING VALVE
72
VALVE (FILLING VALVE)
75
LINE PRESSURE SENSOR
78
T-FITTING DISTRIBUTOR CONNECTION
81
PRESSURE SENSOR PRESSURE SENSOR, TO BE ADAPTED DURING ASSEMBLY EXHAUST STOCK OF OLD PART NUMBER FIRST
81
SENDER UNIT PRESSURE SENSOR
81
PRESSURE SENSOR. SENDER UNIT PRESSURE SENSOR, TO BE ADAPTED DURING ASSEMBLY
84
INTERMEDIATE PIECE FROM T-FITTING TO CHECK VALVE
84
INTERMEDIATE PIECE DISTRIBUTOR CONNECTION
87
CROSS FITTING DISTRIBUTOR
90
SCREW THREE-WAY FAUCET
93
BALL VALVE (BALL COCK)
93
VALVE (BALL COCK), Replaced By: A0004761390
96
T-FITTING , Replaced By: A0009904387
99
FITTING THREE-WAY FAUCET
100
LINE TO PRESSURE GAUGE
105
FITTING FILLING VALVE
108
GASKET PRESSURE GAUGE
111
PRESSURE GAUGE
113
LINE BALL VALVE TO GAS FILTER
115
GUIDE SIGN
119
FUEL FILTER
120
GASKET GASKET KIT
121
FILTER ELEMENT
122
LINE
123
T-FITTING SOLENOID VALVE
126
SEAL RING
129
SOLENOID VALVE (SOLENOID VALVE), WITH FIRST EXCHANGE FROM A0004765632 TO A0014764232 THE PART NO. A6284709173,A6284406057,A0039906170,A0259970045 MUST ALSO BE ORDERED.
129
VALVE (SOLENOID VALVE)
130
SOLENOID VALVE (SOLENOID VALVE), WITH FIRST EXCHANGE FROM A0004765632 TO A0014764232 THE PART NO. A6284709173,A6284406057,A0039906170,A0259970045 MUST ALSO BE ORDERED.
132
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
135
FITTING THREE-WAY FAUCET ON PRESSURE REDUCING VALVE
137
LINE , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.12.2010
137
GAS PIPE SOLENOID VALVE TO PRESSURE REGULATOR TO A0014764232
142
FITTING AT PRESSURE REGULATOR
145
FITTING
148
FITTING. T-FITTING AT PRESSURE REGULATOR
151
HOSE PRESSURE REGULATOR ON INTAKE CASE, ORDER BY THE METER
154
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
999
BRACKET PRESSURE GAUGE
