Поз.
Артикул
Описание
10
AIR DISTRIBUTOR INSIDE,BELOW INSTRUMENT PANEL
12
ADHESIVE TAPE , ORDER BY THE METER
15
DUCT
20
DUCT
22
DUCT DRIVER S WORKPLACE
25
DUCT COOLING AIR INTAKE
35
AIR TUBE BETWEEN HEATER AND AIR DISTRIBUTOR TO BRACKET D48MM
37
HOSE BETWEEN HEATER AND AIR DISTRIBUTOR TO BRACKET D48MM
38
CLAMP SUCTION LINE TO OIL PUMP 40-60X13 MM
40
HOSE BETWEEN HEATER AND DRIVER'S SEAT PEDESTAL 90 MM
42
CLAMP INTAKE MUFFLER TO BRACKET 90-110X12
55
AIR BAFFLE DRIVER'S PEDESTAL
80
VALVE , 000,001,004,010 FROM CHASSIS 152806,002,003,005,011 FROM CHASSIS 012120,100,101,104,110 FROM CHASSIS 267733
86
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
88
DUCT COVER TO AIR DUCT
89
COVERING
89
COVERING
94
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
95
EDGE GUARD SECTION , ORDER BY THE METER
140
SHEET METAL SCREW BRACKET TO SUPPORT
140
SHEET METAL SCREW MODULE TO HOUSING
145
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
160
RIVET COVERING TO BRACKET
180
LOCK NUT MOUNTING, COVER, THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019900856
180
SPRING NUT
185
BRACKET
999
LOOM TIE LINE MOUNTING 150 X 3,6 MM
