Поз.
Артикул
Описание
5
OIL TANK ENGINE OIL AUTOMATIC REPLENISHMENT " GROENEVELD "
8
CAP OIL REFILLING
9
CAP OIL FILLING
10
GASKET , Replaced By: A1020180080
14
SCREW PLUG
15
SEAL RING SOLENOID VALVE A 18X24
20
HOSETO 346 500 60 03, ORDER BY THE METER
20
PLASTIC PIPE. HOSE FLUID LEVEL INDICATOR 170 MM, ORDER BY THE METER
23
PLASTIC PIPE AERATION, ORDER BY THE METER
26
PLASTIC PIPE RISING PIPE 4X6 MM
30
ELBOW FITTING
32
ELBOW FITTING
35
ELBOW FITTING RETURN
38
FITTING COOLING WATER INLET FOR AIR COMPRESSOR
41
SEAL RING VALVE TO VALVE,K 025179
56
STRAP OIL TANK
59
RUBBER MAT ON BRACKET
70
PLUG AT OIL TANK 240X90X5 MM
70
RUBBER MAT AT OIL TANK 240X90X5 MM, Replaced By: A0009973735
72
PLUG AT OIL TANK 240X90X5 MM
75
RUBBER MAT
80
RUBBER MAT234,5X52X5,101397 FROM IDENT NO. WEB 103286103474
110
CONTROL UNIT AT OIL TANK
115
COVER BLACK
120
COVER TRANSPARENT
125
FULL FACE GASKET
130
SEAL RING22,2X3,5 MM
135
SEAL RING17X3 MM
140
BANJO UNION
145
ELBOW FITTING DIA., 10MM
150
CABLE HARNESS
