Поз.
Артикул
Описание
2
PARTICULATE CONVERTER
2
CATALYST
2
CATALYST
3
NUT. CLAMPING RING
4
SENDER UNIT TEMPERATURE SENSOR,EXHAUST
5
EXHAUST PIPE
5
EXHAUST PIPE , Replaced By: A6284903319
5
EXHAUST PIPE , UNTIL PRODUCTION BREAKPOINT DATE 14.02.08
6
EXHAUST PIPE , AS OF PRODUCTION BREAKPOINT DATE 15.02.08
7
EXHAUST PIPE AT MUFFLER 120 MM, FROM IDENT NO. 097921
8
REAR EXHAUST PIPE
10
END PIECE , Replaced By: A3574921314
14
BRACKET
16
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
16
BRACKET
17
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09, Replaced By: A6284905340
17
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
18
BRACKET
18
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
19
HEXAGON HEAD BOLT
20
PROTECTIVE PLATE
21
PROTECTIVE PLATE
24
DASHPOT
24
INSULATION
28
BLIND RIVET. RIVET NAME PLATE TO BRACKET
30
CLAMP EXHAUST SYSTEM D124,5MM, Replaced By: A6554920140
30
CLAMP , Replaced By: N071555124501
31
CLAMP
31
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
32
CLAMP EXHAUST SYSTEM, AS OF PRODUCTION BREAKPOINT DATE 15.02.08
34
HEXAGON HEAD BOLT AUTOMATIC TRANSMISSION AT ENGINE M10X60
35
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
35
SCREW BRACKET TO SIDE MEMBER M10X35
35
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
35
SCREW SHIFT LEVER TO BRACKET M8X30
36
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
36
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
37
SCREW CLAMP TO EXHAUST PIPE
40
SCREW , Replaced By: N910143008002
41
SCREW SHIFT LEVER TO BRACKET M8X30
45
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
46
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
46
HEXAGON NUT. NUT , Replaced By: N913023008002
46
NUT ENGINE MOUNTING M8
46
NUT HORN TO BRACKET M8
47
NUT HORN TO BRACKET M8
68
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
68
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
68
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09, Replaced By: A6284905640
70
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
70
BRACKET , UNTIL PRODUCTION BREAKPOINT DATE 28.02.09
92
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
93
STUD THROTTLE HOUSING TO EXHAUST GAS TURBOCHARGER
120
PRESSURE LINE REDUCING AGENT, AS OF PRODUCTION BREAKPOINT DATE 15.02.08
120
DELIVERY LINE REDUCING AGENT
120
DELIVERY LINE REDUCING AGENT, Replaced By: A4571402355
140
SCREWTO A957 490 05 14
141
SEAL RING
236
HEXAGON HEAD BOLT
242
WATER NOZZLE REDUCING AGENT ADBLUE, AS OF PRODUCTION BREAKPOINT DATE 15.02.08
243
THREADED PLATE , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
245
SCREW TURBOCHARGER TO EXHAUST COLLECTOR PIPE
245
CAP BOLTM10X25, Replaced By: A0009908712
246
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
248
CONNECTOR , AS OF PRODUCTION BREAKPOINT DATE 15.02.08
251
CLAMP
254
CLAMP
257
SCREW STOP TO BATTERY CASE
260
SCREW LEVER TO ENGINE CONTROL SHAFT
260
HEXAGON HEAD BOLTM6X16, AS OF PRODUCTION BREAKPOINT DATE 15.02.08
263
WASHER PUMP TO CONSOLE
266
BRACKET FROM INJECTION NOZZLES TO CONNECTOR, AS OF PRODUCTION BREAKPOINT DATE 15.02.08
269
NUT END PIECE TO EXHAUST PIPE
272
HEAT SHIELD , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
275
BRACKET , AS OF PRODUCTION BREAKPOINT DATE 01.03.09
