Поз.
Артикул
Описание
47
NUT HORN TO BRACKET M8
100
BRACKET
100
BRACKET , Replaced By: A6284906840
102
BRACKET
104
PROTECTIVE PLATE
106
METERING EQUIPMENT
106
METERING DEVICE , Replaced By: A0001400739
106
METERING EQUIPMENT , Replaced By: A0001404139
107
FILTER ADBLUE METERING DEVICE TO A000 140 05 78
108
PRESSURE SENSOR
108
SENDER UNIT , Replaced By: A0061537428
109
SENDER UNIT , Replaced By: A0061537528
109
PRESSURE SENSOR
110
TEMPERATURE SENSOR. SENDER UNIT
111
SCREW-IN FITTING. FITTING
111
FITTING , Replaced By: A0029977871
112
SEALING RING. SEAL RING
114
BUSHING
116
FITTINGTO A 000 140 05 39
116
SCREW-IN FITTING. FITTINGTO A 000 140 07 39
118
SEALING RING. SEAL RINGTO A 000 140 05 39
120
PRESSURE LINE REDUCING AGENT, AS OF PRODUCTION BREAKPOINT DATE 15.02.08
120
DELIVERY LINE REDUCING AGENT, Replaced By: A4571402355
120
DELIVERY LINE REDUCING AGENT
122
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
122
CLAMP10/20MM
124
SCREW PIPE ELBOW TO BRACKET M8X12
125
SCREW , Replaced By: N910143008000
126
SCREW BRACKET TO CAB REAR PANEL M 8X20
127
SCREW. HEXAGON HEAD BOLT GGVS-COMPONENT IN BATTERY CARRIER M8X55
