Поз.
Артикул
Описание
6
FRAME
9
FRAME REAR, .......I.......INO.7E87I.......I II
14
BLIND RIVET NUTM8
15
GLASS PANE DOUBLE GLAZING,GREY
15
GLASS PANE SINGLE GLAZING,GREEN
15
GLASS PANE DOUBLE GLAZING,GREY
15
GLASS PANE SINGLE GLAZING,GREY
15
GLASS PANE DOUBLE GLAZING,GREEN
20
GLASS PANE SINGLE GLAZING,GREEN
20
GLASS PANE DOUBLE GLAZING,GREEN
20
GLASS PANE DOUBLE GLAZING,GREY
20
GLASS PANE DOUBLE GLAZING,GREY
20
GLASS PANE SINGLE GLAZING,GREY
30
SEGMENT SEAL FRONT
35
SEGMENT SEAL
40
DOOR PULL HANDLE , STATE COLOR NUMBER WHEN ORDERING
40
DOOR PULL HANDLE INSIDE, STATE COLOR NUMBER WHEN ORDERING
45
ADHESIVE TAPE COVER TO AIR DUCT 1200 MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
45
ADHESIVE TAPE3900 MM
45
ADHESIVE TAPE BETWEEN PANE AND DOOR WING 6000 MM
45
ADHESIVE TAPE , ORDER BY THE METER
50
RUBBER SEAL TOP
55
RUBBER SEAL
55
SEAL
60
SEAL REAR
60
RUBBER SEAL
65
METAL SECTION
65
METAL SECTION FINGER PROTECTION RUBBER
70
METAL SECTION
70
METAL SECTION FINGER PROTECTION RUBBER
71
PLATE
75
TAPPING SCREW4,2X16
76
BRACKET , EXHAUST STOCK OF OLD PART NUMBER FIRST
76
BRACKET , Replaced By: A6287601928
77
SCREWM8X16
78
ROLLER CARRIER
80
HEXALOBULAR BOLT BRACKET ON TUBULAR SUPPORTING FRAMEWORK M6X12
80
HEXALOBULAR BOLT BASIC MODULE AT SUPPORT M6X16,01.08.08
80
STUD , Replaced By: N000000001475
82
SCREW W SOCKET DRIVEM8X20
82
SCREW
90
GUIDE
90
GUIDE
93
SCREWM 8X25
999
WELT , Replaced By: A0079896185
999
EDGE GUARD SECTION , Replaced By: A0099875751
999
CONNECTOR2X1, 500MM
999
ADHESIVE
999
ADHESIVE TAPE4.5X10 MM, ORDER BY THE METER
999
SEAL LEFT BOTTOM
999
SEAL RIGHT BOTTOM
