Поз.
Артикул
Описание
30
SCREW BRACKET TO CAB REAR PANEL M 8X20
52
RUBBER MOUNTING
54
RUBBER MOUNTING MOUNTING FOR PRESSURE AND RETURN LINE 28MM
56
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
56
CLAMP ,K 147121, Replaced By: N000000000319
57
CLAMP , Replaced By: N916016010211
57
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
59
CLAMP8/20 RSGU
59
CLAMP BATTERY CABLE MOUNTING
65
CLAMP OIL FILLER PIPE TO BRACKET
65
CLAMP AT SUPPORT 30/15MM, Replaced By: A0019951942
68
CLAMP42/20, Replaced By: N000000007548
68
CLAMP CLAMP TO CROSS MEMBER 42/20
70
BANJO BOLT. HOLLOW SCREW
73
SEAL RING CHECK VALVE,CONNECTION "1",4 704213
100
103
103
VALVE , Replaced By: A0005508455
106
COVER VALVE BLOCK
109
SEAL BLEED CONNECTION TO RESERVOIR 32X2MM
119
LOCK
134
PLATE
140
TRAY
143
PLATE30MM
153
SCREW PLATE TO VALVE M 6X60
162
SCREW. HEXAGON HEAD BOLT CONTROL MODULE TO SUPPORT PLATE M6X50
163
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
163
SCREW , Replaced By: N914146006102
165
NUT BRACKET TO FIRE WALL
174
SCREW SHIFT LEVER TO BRACKET M8X30
178
SCREW , Replaced By: N910143008002
179
SCREW GRIP RAIL MOUNTING M8X25 TX45
185
SCREW PIPE ELBOW TO BRACKET M8X12
188
NUT HORN TO BRACKET M8
196
PIPE LINE OIL RETURN
197
SEAL BLEED CONNECTION TO RESERVOIR 32X2MM
208
PIPE LINE OIL RETURN
209
SEAL BLEED CONNECTION TO RESERVOIR 32X2MM
211
PIPE LINE ON DELIVERY SIDE
212
SEAL BLEED CONNECTION TO RESERVOIR 32X2MM
220
PIPE LINE
