Поз.
Артикул
Описание
320
321
INSULATING HOSE22X32MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
322
FITTING
323
FLANGE THREADED D36MM
324
FLANGE NOT THREADED D36MM
330
331
INSULATING HOSE28MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
332
FITTING
333
FLANGE THREADED D36MM
334
FLANGE NOT THREADED D36MM
340
PIPE LINE
341
INSULATING HOSE22X32MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
342
FITTING
343
FLANGE THREADED D36MM
344
FLANGE NOT THREADED D36MM
350
PIPE LINE
351
INSULATING HOSE28MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
352
FITTING
353
FLANGE THREADED D36MM
354
FLANGE NOT THREADED D36MM
360
HOSE LINE FEED, REAR LEFT, TOP 570 MM
370
HOSE LINE RETURN, REAR LEFT, TOP 610 MM
600
NUT BRACKET TO FIRE WALL
625
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
630
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
705
CLAMP28/15, Replaced By: A0019951842
705
MOUNTING CLAMP28/15
705
CLAMP CABLE HARNESS MOUNTING
725
CLAMP35/20
725
CLAMP35/20, Replaced By: N000000007514
725
CLAMP COOLING WATER HOSES
812
BRACKET
865
GASKET34X42 MM
999
FLAME PROTECTOR
999
LOOM TIE LINE MOUNTING
999
CABLE TIE LINE MOUNTING 375X8.4MM
999
ADHESIVE TAPE3X50MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
