Поз.
Артикул
Описание
12
SCREW BRACKET TO FRAME
12
SCREW BRACKET TO SIDE MEMBER M10X35
12
SCREW BRACKET TO CAB REAR PANEL M 8X20
12
SCREWM 10X20
12
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
12
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
12
SCREW , Replaced By: N304017010002
13
NUT , Replaced By: N913023010002
13
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
13
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
13
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
14
BRACKET
14
BRACKET
36
ADAPTER FITTING NARROWED STRAIGHT SURFACE 70/65MM
36
SLEEVE. ADAPTER FITTING REDUCED 70/65MM
36
HOSE FEED AND RETURN LINES TO OIL COOLER, Replaced By: A0015013782
36
MOLDED HOSE NARROWED STRAIGHT SURFACE 65/60
37
SCREW BRACKET AND CLAMP M6X20
38
NUT MOUNTING FRAME TO SUPPORT M6
38
NUT , Replaced By: N913023006001
41
COOLING WATER PIPE FEED D60MM
41
COOLING WATER PIPEL900MM
43
CLAMP70 / 25
45
HOSE70X82X180MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
45
HOSE RETURN, FROM RETARDER TO ENGINE
45
RADIATOR HOSED70/L180MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
45
HOSE. RADIATOR HOSE150LG, UNTIL PRODUCTION BREAKPOINT DATE 05.01.05 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
45
HOSE. RADIATOR HOSED70/L180MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY, Replaced By: N000000005014
45
HOSE RETURN, FROM RETARDER TO ENGINE, Replaced By: N000000005010
47
LINE FEED D60MM
47
COOLING WATER PIPEL1110MM, FROM IDENT NO. WEB 629011 13 520359 ALSO INSTALLED ON WEB 629011 13 520304 , WEB 629011 13 520309 , EXCEPT FOR WEB 629011 13 520375
47
COOLING WATER PIPEL1500MM
48
LINE RETURN D60MM,WEB 629011 13 521241
48
LINE RETURN
48
COOLING WATER PIPE COOLING WATER RETURN D60MM
51
MOLDED HOSE ARC REDUCED 90 DEGREES 15/10MM
51
MOLDED HOSE REDUCED 15/10MM
52
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
54
COOLING WATER PIPEL60MM
55
RADIATOR HOSENW10/L850MM, Replaced By: N000000004939
55
RADIATOR HOSE , Replaced By: A0015014282
55
HOSE10X19X850MM
55
MOLDED HOSE NARROWED STRAIGHT SURFACE 22/15, EXHAUST STOCK OF OLD PART NUMBER FIRST
55
RADIATOR HOSENW10/L850MM
55
RADIATOR HOSEL1000MM
56
CABLE STRAP7.8X465
57
CONNECTOR
57
THROTTLE
58
CLAMP PIPE ON FAN SHROUD
58
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
58
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
58
CLAMP HOSE TO FITTING 11 - 20 MM
61
COOLING WATER PIPEL620MM
61
COOLING WATER PIPE38X1X60MM
62
RADIATOR HOSE38X100MM, Replaced By: N000000004992
62
RADIATOR HOSENW38
62
HOSE ,D 209702
62
RADIATOR HOSED38/100MM
63
CLAMP HOSE TO INTAKE PIPE 35-50X13MM
65
SCREW SHIFT LEVER TO BRACKET M8X30
65
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
67
NUT HORN TO BRACKET M8
67
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
69
HOSE
69
HOSE12X21X900MM, TO BE ADAPTED DURING ASSEMBLY
69
RADIATOR HOSEL850MM
69
RADIATOR HOSED12/L900MM
69
HOSE. RADIATOR HOSED12/L850MM, Replaced By: N000000004957
69
RADIATOR HOSE , Replaced By: N000000004947
71
CABLE TIE LINE MOUNTING 375X8.4MM
73
HOSE NARROWED STRAIGHT SURFACE 70/60MM
73
HOSE RADIATOR TO ENGINE 70X82X220MM
73
HOSE RADIATOR TO ENGINE 220 X 70 MM, Replaced By: N000000005015
73
HOSE. RADIATOR HOSE150LG, UNTIL PRODUCTION BREAKPOINT DATE 05.01.05 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
74
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
75
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
75
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
81
MOLDED HOSE ARC REDUCED 90 DEGREES 70/60MM
81
MOLDED HOSE 90-DEGREE ARC 70MM
81
MOLDED HOSE 90 DEGREES 70MM
82
CLAMP
999
MOLDED HOSE 90 DEGREES 50MM
999
MOLDED HOSE ENGINE CONNECTION
999
LINE COOLING WATER LINE
999
HEXAGON HEAD BOLT AIR DEHYDRATOR TO BRACKET M12X55,V 207570
