Mercedes A6296800017 - LU DECKEL, KUEHLTRUH

O580 TRAVEGO 17RHD 629.012

68 PANELLING AND LINING - 330 INSTRUMENT PANEL IL. 1

Поз.
Артикул
Описание
5
A6298300460
DEEP FREEZER COMPLETE
8
A0008430218
GRILLE WIDE
11
A0008430318
GRILLE NARROW
14
A0008357079
THERMOSTAT
17
A0009914571
RETAINING CLIP
20
A6278330013
KNOB
23
A0058206010
SWITCH (PRESSURE SWITCH)
26
A0018205801
INTERIOR LAMP
29
N072601024131
BULB24V/5W
32
A0018350214
BRACKET FUSE HOLDER
35
Q0026011007
FUSE F.FEEBLE CURRENT5A
38
A0019970649
GASKET
41
A0018305660
REFRIGERATION ON SET
44
A0018306060
COMPRESSORR134
47
A0008358036
CONTROL UNIT
50
A0008307170
CONDENSER
53
A0008354607
BLOWER
56
A0008341569
DEHYDRATOR
59
A0008354734
COVER ADJUSTER
62
A0009909710
SCREW3.5X13 MM
65
A0008440084
FASTENER
68
A0009871843
HOSE TRANSPARENT D20X3, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
71
A0029978974
T-FITTING
72
N910105008060
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M8X35
73
A0009902029
SCREW W SOCKET DRIVEM6X25 T30
74
A0009902029
SCREW W SOCKET DRIVEM6X25 T30
75
N910104008000
NUT GUIDE RAIL,REAR BOTTOM
75
N913023008003
NUT HORN TO BRACKET M8
76
A3819900740
WASHER BRACKET TO CONSOLE
77
A0008270451
HINGE
79
A6296800017
COVER REFRIGERATOR
999
A0058176420
GUIDE SIGN
