Поз.
Артикул
Описание
5
COMPRESSORFKX40/470K, TO BE ADAPTED DURING ASSEMBLY
5
COMPRESSOR , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6298309460
5
COMPRESSOR , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6298309460
110
COUPLING
111
MAGNETIC RING
114
GROOVED BALL BEARING REPAIR KIT TO A 001 830 49 72
115
SCREW MAGNETIC COUPLING FA LINNIG
116
SWITCH HIGH PRESSURE 18/22BAR
116
PRESSURE MONITOR HIGH PRESSURE 18/22 BAR
116
PRESSURE MONITOR HIGH PRESSURE 18/22BAR, Replaced By: A0008331150
116
PRESSURE MONITOR HIGH PRESSURE 20/25BAR
117
SWITCH LOW PRESSURE 0,2/0,4BAR
117
PRESSURE MONITOR LOW PRESSURE 0.2/0.4 BAR
117
PRESSURE MONITOR LOW PRESSURE 0,2/0,4BAR, Replaced By: A0008331050
120
SEAL7/16"
120
SEAL RING
123
FITTING601-7313
126
COOLANT LINE LOW PRESSURE 550MM
126
COOLANT LINE
126
HOSE LOW PRESSURE 550MM, Replaced By: A0008306096
129
HOSE HIGH PRESSURE 370MM
129
COOLANT LINE. PIPE LINE HIGH PRESSURE 540MM
138
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM
138
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
138
CLAMP LINE MOUNTING
141
SCREW BRACKET AND CLAMP M6X20
144
NUT BRACKET TO FIRE WALL
147
LOOM TIE
999
GUIDE SIGNDEA SE 55
999
GUIDE SIGNR134A
999
SCREW AUXILIARY FRAME MOUNTING
