Поз.
Артикул
Описание
23
FRAME
26
SEAT SHELL
35
SCREW ASHTRAY MOUNTING
41
TAPPING SCREW3.5X16
50
SEAT CUSHION , STATE IDENT NO. WHEN ORDERING
62
TAPPING SCREW3.5X22
101
BUSHING
116
LEVER LEFT
122
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
125
TENSION SPRING
125
SPRING TENSION SPRING
128
HANDLE
131
GAS SPRING
134
HEXAGON HEAD BOLT. SCREW CONSOLE TO COWL AND TO ROOF
137
NUT HEATING PIPE TO BRACKET
140
LOCK RING SLIDE TO RETAINING RAIL
143
BUSHING
146
SCREW GRIP RAIL MOUNTING M8X25 TX45
149
WASHER PUMP TO CONSOLE
182
WASHER8,1X16X2MM
314
BUSHING
317
BUSHING BELT LOCK MOUNTING
323
FASTENER
323
FASTENER
326
SCREWM10X32MM
380
PLATE
392
HEXAGON HEAD BOLTM8X30
392
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
392
SCREW SHIFT LEVER TO BRACKET M8X30
392
HEXAGON HEAD BOLT. SCREW STAY TO APPARATUS SUPPORT
395
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
425
SWITCH
428
ANGLE
431
PLUG HOUSING
434
TAPPING SCREW MOUNTING PLATE 3.5X9.5
569
WASHER COMPRESSED AIR LINE TO BRACKET
999
DRIVE SHAFT
999
SPINDLE
999
GEAR
999
CLIP
