Поз.
Артикул
Описание
17
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
17
SCREW BRACKET TO CAB REAR PANEL M 8X20
17
SCREW BRACKET TO SIDE MEMBER M10X35
20
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
20
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
62
HOSE FEED AND RETURN LINES TO OIL COOLER, Replaced By: A0015013782
62
MOLDED HOSE NARROWED STRAIGHT SURFACE 65/60
62
SLEEVE. ADAPTER FITTING REDUCED 70/65MM
62
ADAPTER FITTING NARROWED STRAIGHT SURFACE 70/65MM
68
COOLING WATER PIPEL900MM
68
COOLING WATER PIPE FEED D60MM
71
CLAMP70 / 25
74
HOSE. RADIATOR HOSE150LG, UNTIL PRODUCTION BREAKPOINT DATE 05.01.05 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
74
HOSE RETURN, FROM RETARDER TO ENGINE, Replaced By: N000000005010
74
HOSE RETURN, FROM RETARDER TO ENGINE
74
HOSE. RADIATOR HOSED70/L180MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY, Replaced By: N000000005014
74
RADIATOR HOSED70/L180MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
80
COOLING WATER PIPE COOLING WATER RETURN D60MM
80
LINE RETURN
80
LINE RETURN D60MM,WEB 629011 13 521241
83
MOLDED HOSE REDUCED 15/10MM
83
MOLDED HOSE ARC REDUCED 90 DEGREES 15/10MM
86
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
89
COOLING WATER PIPEL60MM
92
HOSE10X19X850MM
92
RADIATOR HOSEL1000MM
92
RADIATOR HOSENW10/L850MM
92
MOLDED HOSE NARROWED STRAIGHT SURFACE 22/15, EXHAUST STOCK OF OLD PART NUMBER FIRST
92
RADIATOR HOSENW10/L850MM, Replaced By: N000000004939
92
HOSED22/15,LG850, EXHAUST STOCK OF OLD PART NUMBER FIRST, Replaced By: A0015014282
95
CABLE STRAP7.8X465
98
CONNECTOR
98
THROTTLE
101
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
101
CLAMP HOSE TO FITTING 11 - 20 MM
101
CLAMP CLAMP ON TRANSVERSE SHAFT MOUNTING, LINKAGE
101
CLAMP PIPE ON FAN SHROUD
104
COOLING WATER PIPEL620MM
104
COOLING WATER PIPE38X1X60MM
107
RADIATOR HOSED38/100MM
107
HOSE ,D 209702
107
RADIATOR HOSENW38
107
RADIATOR HOSE38X100MM, Replaced By: N000000004992
107
HOSE LINE CONNECTION 38X50X100 MM
110
CLAMP HOSE TO INTAKE PIPE 35-50X13MM
113
SCREW BRACKET AND CLAMP M6X20
113
SCREW SHIFT LEVER TO BRACKET M8X30
113
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
116
NUT , Replaced By: N913023006001
116
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
116
NUT HORN TO BRACKET M8
119
HOSED12, 900 MM, TO BE ADAPTED DURING ASSEMBLY
119
RADIATOR HOSE , Replaced By: N000000004947
119
HOSE. RADIATOR HOSED12/L850MM, Replaced By: N000000004957
119
RADIATOR HOSED12/L900MM
119
HOSE
122
CABLE TIE LINE MOUNTING 375X8.4MM
128
CLAMP
185
BRACKET
188
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
191
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
212
COOLING WATER PIPEL1110MM, FROM IDENT NO. WEB 629011 13 520359 ALSO INSTALLED ON WEB 629011 13 520304 , WEB 629011 13 520309 , EXCEPT FOR WEB 629011 13 520375
215
HOSE NARROWED STRAIGHT SURFACE 70/60MM
215
HOSE. RADIATOR HOSE150LG, UNTIL PRODUCTION BREAKPOINT DATE 05.01.05 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
215
RADIATOR HOSED70/LG220
215
HOSE RADIATOR TO ENGINE 220 X 70 MM, Replaced By: N000000005015
218
MOLDED HOSE 90 DEGREES 70MM
218
MOLDED HOSE 90-DEGREE ARC 70MM
218
MOLDED HOSE ARC REDUCED 90 DEGREES 70/60MM
