Поз.
Артикул
Описание
188
SLIDE
195
PIPE BEND
195
MOLDED HOSE FROM HEATING WATER PIPE TO HEATER
196
MOLDED HOSE 90-DEGREE ARC D38
200
HOSE ,D 209702
200
HOSE LINE CONNECTION 38X50X100 MM
203
HOSE
203
HOSE22X31X100MM
207
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
212
CLAMP HOSE TO INTAKE PIPE 35-50X13MM
215
MOUNTING CLAMP22/15
215
CLAMP DELIVERY AND SUCTION LINES TO FRAME
215
CLAMP22/15, Replaced By: A0019951442
218
CLAMP LINE MOUNTING
218
CLAMP , Replaced By: A3829950701
221
BRACKET
227
SCREW BRACKET AND CLAMP M6X20
230
SCREW , Replaced By: N910143008002
233
NUT , Replaced By: N913023006001
236
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
240
NUTM8
241
LOCK NUT. SPRING NUT MOUNTING PARTS
256
PIPE LINE COOLING WATER HOSE D38/130MM,WKK 632131 13 000191
259
HEATING PIPE FEED
259
PIPE LINE RETURN
261
HEATING PIPE3810LG
264
PIPE LINE RETURN
269
PIPE LINE1700LG
272
PIPE LINE1200LG
275
PIPE LINE1850LG
999
PIPE LINE
999
PIPE LINE2270LG
999
PIPE LINED38/L2250MM
999
PIPE LINE2450LG
999
PIPE LINE2430LG
999
SERVO-D.C. W.GEARBOX
