Поз.
Артикул
Описание
17
COVERING
146
BLOWER24V
215
MORTISE LOCK. FASTENER WASHROOM DOOR
218
RUBBER SECTION WASHROOM DOOR, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
221
BUFFER WASHROOM DOOR
224
SWITCH WASHROOM DOOR
227
SWITCH DOOR LOCK
230
STOP DOOR STOP
233
MOUNTING
236
RUBBER SECTION WASHROOM DOOR, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
239
CAP PLASTIC
242
PIPE SOCKET RADIAL BLOWER
245
SEAL
246
SCREEN
248
HOSE
248
HOSE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
251
SQUARE KEY WASHROOM DOOR
272
GUIDE SIGN W.C.
281
DOOR HANDLE VACANT-OCCUPIED SET
284
SEAL
299
DOORM. RESOPAL ABET PRENT 877 ALU
299
W.C. DOOR. W.C. DOORRHD, DETERMINE COVER FABRIC VIA VEDOC "NFC 5117"
302
GASKET , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
305
SCREW BRACKET TO SIDE MEMBER M8X20
308
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
311
COVERING
314
TAPPING SCREW BRACKET TO CAB FLOOR 3.5X9.5
317
COVERING
317
COVERING
317
COVERING
320
SHEET METAL SCREW. SCREWST25X 6 T20
323
LOCKING CAP
326
FIXTURE
329
DRAIN WATER DRAIN
332
BOTTOM , Replaced By: A0009837380
332
BOTTOM , Replaced By: A0009837380
332
FLOOR , Replaced By: A0009837380
332
PLYWOOD , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
335
ADHESIVE STRIP. BASE40 X 2 MM
338
TAPPING SCREW BRACKET MOUNTING 3.5X25
344
CAP GRIP RAIL
356
COVERING
486
FITTING
492
FASTENER PNEUMATICALLY CONTROLLED
494
FASTENER MECHANICAL
497
LOUDSPEAKER. LOUDSPEAKER
497
LOUDSPEAKER , Replaced By: A0008275760
515
COVERINGH - PROFIL, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
FASTENER
999
VALVE FECES CONTAINER
999
RESERVOIR ASHTRAY
999
COMPRESSED AIR LINE
999
KEY
999
SEAL
999
FITTING
