Поз.
Артикул
Описание
8
PUMP MODULE , Replaced By: A0001402578
8
PUMP MODULE , Replaced By: A0001400578
11
VALVE CRANKCASE BREATHER
14
FILTER ELEMENT WITH COVER, Replaced By: A0001420289
14
FILTER ELEMENT WITH COVER
15
HEXALOBULAR BOLT RESERVOIR BLADDER AT PUMP MODULE M5X16, TO 000 140 04 78,V 207570
17
STRAINER ON SUCTION SIDE
17
STRAINER ON SUCTION SIDE
20
FITTING COOLING WATER INLET/OUTLET M14X1.5 / 10MM, FROM 01.07.09
23
FITTING ADBLUE OUTPUT
26
FITTING UREA,RETURN LINE
26
FITTING ADBLUE RETURN LINE
29
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 10, VOSS 232, Replaced By: A0009975034
32
ELECTRIC MOTOR
33
PLUG BIPOLAR, Replaced By: A0025402781
34
PLUG
36
RESERVOIR BLADDER
36
ACCUM. BAGTO A 000 140 44 78
37
DUST CAP
37
DUST PROTECTION CAP RESERVOIR BLADDER 11X10.5 MM
38
COVERTOA0001400378
41
GASKET HOUSING TO COVER
44
GROMMET SEAL
50
BRACKET ,WKK 629410 13 102802, Replaced By: A0004700781
53
SOLENOID VALVE. VALVE
56
SPACER SLEEVE. SPACER TUBE VALVE TO CRANKCASE
59
COUPLING , Replaced By: A0059970289
59
COUPLING
62
CONNECTOR12-90GRAD
65
PLUG CONNECTOR HEATING WATER CONNECTION 90 GRAD, TO 000 140 02 78
74
HOSE271-15X24X2000, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
74
RADIATOR HOSE , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)30.11.2009 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
77
RADIATOR HOSE9X3.5 MM, ORDER BY THE METER
80
FUEL HOSE. HOSEB5,5-2,5,WEB 629012 13 520122 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
83
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
86
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
89
GROMMET
92
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
92
CLAMP , Replaced By: N916016010211
92
CLAMP10/15
95
CLAMP LINE MOUNTING
104
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
104
SCREWM 10X20
104
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
107
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
110
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
113
SCREW , Replaced By: N910143008000
119
SCREWM6X65
122
SCREW , Replaced By: N914146006102
122
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
125
NUT , Replaced By: N913023006001
128
WASHER BRACKET TO CAB REAR PANEL
131
LOCK NUT. SPRING NUT MOUNTING PARTS
131
NUTM8
137
CLAMP
260
UREA CONTAINER
260
UREA CONTAINER
263
SENDER UNIT
266
FILLER NECK , FROM 01.07.09
269
FILLER CAP NON-KEY LOCKING
272
SEAL RING
275
FEED CONNECTION UREA,FEED LINE
278
FEED CONNECTION
281
PRESSURE RELIEF VALVE , FROM 01.07.09
284
ELEMENT ANTI-CONFUSION PROTECTION
287
SEAL RING
287
SEAL RING
293
SUCTION LINE
296
RISING PIPE
299
SCREW BRACKET TO CAB REAR PANEL M 8X20
302
BRACKET
305
SCREW , Replaced By: N910143008009
308
COVERING
311
FAST-CURE ADHESIVE 242 MEDIUM STRENGTH
999
RANGE SPACER
