Mercedes A6298220006 - Sensor

S 415 HDH 629.421

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 455 PRESSURE SWITCH, TRANSMITTER AND SENSORS IL. 1

Поз.
Артикул
Описание
5
A0115429617
SENDER UNIT OUTBOARD TEMPERATURE FEELER,126372
8
A0065452014
SWITCH DECLUTCHING START UNIT IN ENGINE COMPARTMENT
8
A0055451414
SWITCH (END SWITCH)
11
A0005400684
LEVER
20
A0039908112
SCREWM4X30
23
N000000003718
WASHER ATTACHMENT OF ELECTRIC LEAD AND GROUND STRAP ON ALTERNATOR
26
N304032004004
NUTM 4
29
A0019971173
FITTINGTO A 006 545 20 14 / M 16X1.5
29
A0009979073
FITTING
41
A0135422517
THERMAL CONTACT. SENDER UNIT FIRE-ALARM SYSTEM
150
A4445400145
SWITCH ENGINE COMPARTMENT FIRE DETECTION
153
A0135422517
THERMAL CONTACT. SENDER UNIT FIRE-ALARM SYSTEM
165
A0055455426
PIN BUSHING HOUSING BIPOLAR TO 651 540 36 09
168
A0045455626
CONTACT SPRING , Replaced By: A0055456826
171
A0039908412
HEX. SKT. CAP BOLTM5X16MM
174
A0019907291
CLIP FASTENERM5
177
N000000000461
TAPPING SCREW MOUNTING PARTS 4.8X16
999
A6298220006
SWITCH FRONT BOX
