Поз.
Артикул
Описание
5
HOSE60 X 72 X 100 MM, TO BE ADAPTED DURING ASSEMBLY
5
HOSE50X62X100MM
5
HOSE BLUE 60 X 72 X 100 MM, TO BE ADAPTED DURING ASSEMBLY
5
HOSE. RADIATOR HOSENW50/L100MM
5
RADIATOR HOSE , Replaced By: A0015014982
5
RADIATOR HOSE RUBBER 100MM, Replaced By: N000000005002
5
HOSE SILICONE, Replaced By: N000000005008
5
HOSE COOLING WATER LINE TO COOLING WATER LINE
17
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
17
SCREW BRACKET TO SIDE MEMBER M10X35
17
SCREW BRACKET TO CAB REAR PANEL M 8X20
17
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
20
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
20
NUT , Replaced By: N913023010002
20
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
23
COOLING WATER PIPEL1160MM
23
COOLING WATER PIPE FEED D60RET.1
27
LINE RETURN D 60 RET.2
33
LINE RETURN D60RET.1
34
BRACKET FEED & RETURN
39
LINE FEED D60RET.2
42
BRACKET FEED & RETURN
52
BRACKET
53
BRACKET BRACKET TO TRANSMISSION
56
SCREW PLUG, FILLINGM14X1,5
56
SCREW PLUG FUEL TANK
59
SEAL RINGTO 000 553 03 05,000 553 18 05,
71
CLAMP70 / 25
71
CLAMP60/25
71
CLAMP60/25MM, Replaced By: N000000006126
71
CLAMP60/25RSGU
126
CLAMP CONNECTION OF COOLING WATER LINES 55-75X13MM
127
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 60-80X13 MM
129
CLAMP
131
SCREW , Replaced By: N910143008002
136
RADIATOR HOSE ARC REDUCED 90 DEGREES 65/60MM, Replaced By: A0015013982
136
MOLDED HOSE ARC REDUCED 90 DEGREES 65/60MM, Replaced By: A0025012082
136
COOLANT HOSE 90 DEGREES 60/60MM, Replaced By: A6285017782
136
MOLDED HOSE 90 DEGREES 60/60MM
140
LINE FEED PIPE
140
PIPE SOCKET
140
FILLER NECK
146
GASKET FITTING ON ENGINE
155
MOLDED HOSE NARROWED STRAIGHT SURFACE 60/50MM
155
MOLDED HOSE , Replaced By: A3578322623
155
MOLDED HOSE , Replaced By: N900271060002
167
CONSOLE RETURN
173
SCREW BRACKET TO CAB REAR PANEL M 8X20
176
BRACKET
257
SCREW BRACKET TO SIDE MEMBER M10X35
257
SCREW PICK-UP PLATE BRACKET ON LONGITUDINAL MEMBER M 14X25
257
SCREW. HEXAGON HEAD BOLT BRACKET MOUNTING M14X1.5X25,V 207570
257
SCREW FRONT SPRINGS TO FRONT AXLE
257
SCREW BRACKET TO CAB REAR PANEL M 8X20
257
HEXAGON HEAD BOLT MOUNTING, TORSION BAR, ON SIDE MEMBER M12X1.5X65
257
SCREWM 10X20
257
HEXAGON HEAD BOLT HEAT SHIELD MOUNTING M16X1.5X30
257
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 16X25
266
CONNECTION FITTING
269
GASKET
272
TEMPERATURE SENSOR RETARDER TEMPERATURE
275
SCREW BUMPER TO REAR CROSS MEMBER M 8X50
275
SCREW. HEXAGON HEAD BOLT GGVS-COMPONENT IN BATTERY CARRIER M8X55
275
HEXAGON HEAD BOLT. SCREW BRACKET MOUNTING M8 X 30
276
HEXAGON HEAD BOLTM8X85
276
HEXALOBULAR BOLT SOLENOID VALVE TO BRACKET M8X100
276
HEXAGON HEAD BOLT. SCREW 3/2-WAY VALVE TO BRACKET M 8X100
278
WASHER PUMP TO CONSOLE
279
HEXAGON HEAD BOLTM8X90
454
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
454
SEAL RING FITTING ON ENGINE 58X3.5MM
