Поз.
Артикул
Описание
77
SHEET METAL SCREW. SCREWST25X 6 T20
80
LOCKING CAP
490
COVERING , TO BE ADAPTED DURING ASSEMBLY
499
COVERING LEFT
502
ORNAMENTAL COVER
505
BUSHING
508
BUSHING BELT LOCK MOUNTING
511
BUSHING ATTACHMENT,SEAT BELT TONGUE
514
FASTENER
514
FASTENER
517
SCREWM10X32MM
562
SEAT ADAPTER
565
PLATE
571
SHEET METAL SCREW. SCREWST25X 6 T20
571
TAPPING SCREW RAIL
574
HEXALOBULAR BOLT EXPANSION TANK M8X20
577
HEXAGON HEAD BOLT. SCREW STAY TO APPARATUS SUPPORT
577
SCREW SHIFT LEVER TO BRACKET M8X30
577
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
577
HEXAGON HEAD BOLTM8X30
580
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
592
SWITCH
595
SCREW4.2X32
598
LOCKING CAP
622
ELECTRIC CABLE CO-DRIVER'S SEAT,WEB 629011 13 521248 STATE IDENT NO. WHEN ORDERING
622
ELECTRIC CABLE
622
ELECTRIC CABLE ,WKK 629410 13 101723WKK 629411 13 101837, Replaced By: A6298208004
625
HANDLE
628
COVERING
775
CUSHION FRAME
775
CUSHION FRAME
883
LOCK
886
LEVER
892
COVER , DETERMINE COVER FABRIC VIA VEDOC "NFC 5117"
892
CUSHION COVER SEAT FOR CLIMATE-CONTROLLED SEAT, DETERMINE COVER FABRIC VIA VEDOC "NFC 5117"
892
COVER SEAT CUSHION, COVER LIKE DRIVER SEAT (RECARO), DETERMINE COVER FABRIC VIA VEDOC "NFC 5117"
892
COVER SEAT CUSHION, COVER LIKE PASSENGER SEAT, DETERMINE COVER FABRIC VIA VEDOC "NFC 5117"
900
CLIP
999
GEAR
999
SPINDLE
999
DRIVE SHAFT
