Поз.
Артикул
Описание
80
HOSE. REFRIGERANT LINENW20
83
GASKET34X42 MM
86
CLAMP42/20, Replaced By: N000000007548
89
CLAMP35/20, Replaced By: N000000007514
89
CLAMP35/20
92
CLAMP28/15, Replaced By: A0019951842
92
MOUNTING CLAMP28/15
95
NUTM8
98
SCREW BRACKET TO CAB REAR PANEL M 8X20
101
SCREW SHIFT LEVER TO BRACKET M8X30
104
SCREW BRACKET TO SIDE MEMBER M10X35
107
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
110
HEXAGON HEAD BOLT AUTOMATIC TRANSMISSION AT ENGINE M10X60
113
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
116
BRACKET
119
BRACKET
122
PIPE LINE DELIVERY LINE
125
FITTING
128
FLANGE THREADED D36MM
131
INSULATING HOSE28MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
136
REFRIGERANT LINE DELIVERY LINE
139
FITTINGNW25MM
142
FLANGE THREADED D36MM
142
FLANGE NOT THREADED D36MM
145
PIPE LINE SUCTION LINE
148
FITTING
151
FLANGE NOT THREADED D36MM
151
FLANGE THREADED D36MM
154
INSULATING HOSE36,5X47MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
157
REFRIGERANT LINE COMPRESSOR NW32
160
CONNECTORNW32
163
HOSE
166
SOCKET
