Mercedes
BUS
S 415 HD MODELLPFLEGE
629.612
83 HEATING AND VENTILATION
210 AIR DUCT TO ROOF IL. 2

Mercedes A6298361451 - ABDECKLEISTE

S 415 HD MODELLPFLEGE 629.612

83 HEATING AND VENTILATION - 210 AIR DUCT TO ROOF IL. 2

Поз.
Артикул
Описание
8
A6298361114
BRACKET
65
A6298360714
BRACKET
86
A6298360125
PIPE SOCKET
140
A6298368326
RAIL4300MM
143
A6298363129
RAIL REAR RIGHT 5925MM
143
A6298367220
RAIL REAR LEFT 5925MM
143
A6298367320
RAIL REAR RIGHT 5925MM
143
A6298369320
RAIL REAR RIGHT
143
A6298369220
RAIL REAR LEFT
143
A6298363029
RAIL REAR LEFT 5925MM
143
A6298362829
RAIL FRONT LEFT 2551MM
143
A6298367120
RAIL FRONT RIGHT 2551 MM
143
A6298367020
RAIL FRONT LEFT 2551MM
146
A6298364527
RAIL3000MM
146
A6298364827
RAIL3000MM
146
A6298364727
RAIL3000MM
149
A6298367026
RAIL
155
N910105008041
SCREW , Replaced By: N910143008000
170
A6298362729
RAIL RIGHT FRONT 4948MM
170
A6298365524
RAIL LEFT FRONT 4948MM
170
A6298365224
RAIL REAR LEFT AND RIGHT 6000MM
173
A6298363724
RAIL REAR LEFT AND RIGHT 6000MM
176
A6298360301
PANELLING REAR LEFT AND RIGHT 6000MM
179
A6298360824
RAIL FRONT RIGHT 4930MM
179
A6298362324
RAIL REAR LEFT 5935MM
179
A6298360724
RAIL FRONT LEFT 4930MM
179
A6298362424
RAIL REAR RIGHT 5935MM
182
A6298361214
BRACKET
185
A6298360116
REINFORCEMENT
188
A6298361451
LEDGE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
194
A6298369624
RAIL4300MM
197
A6298360041
COVERING
200
A6298360920
RAIL6000MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
203
A6298363602
COVERING
206
A6298363502
COVERING
206
A6298363402
COVERING
212
A6298300198
SEAL
215
A0008314698
SEAL AIR DUCT
215
A0008315083
CLIP AIR DUCT
215
A0008314598
SEAL AIR DUCT
215
A0009834898
FOAM PLASTICS35X5MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
215
A0008314998
SEAL RIGHT
230
A6298140749
CONNECTOR
245
A6298361714
BRACKET
248
A6298361814
BRACKET
