Поз.
Артикул
Описание
300
MOLDED HOSE ARC REDUCED 45 DEGREES 65/60MM
306
HOSE60 X 72 X 100 MM, TO BE ADAPTED DURING ASSEMBLY
324
COOLING WATER PIPE FEED D60MM
327
LINE60MM
330
COOLANT PIPE RETURN D60
333
LINE. RETURN LINE60MM
349
CONNECTION FITTING
352
GASKET
355
BRACKET
358
BRACKET
361
BRACKET
364
BRACKET
367
BRACKET
373
MOLDED HOSE 90 DEGREES 60/60MM
373
COOLANT HOSE 90 DEGREES 60/60MM, Replaced By: A6285017782
373
MOLDED HOSE ARC REDUCED 90 DEGREES 65/60MM, Replaced By: A0025012082
399
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
406
SCREW BRACKET TO CAB REAR PANEL M 8X20
415
SCREW PLUG, FILLINGM14X1,5
415
SCREW PLUG FUEL TANK
418
SEAL RINGTO 000 553 03 05,000 553 18 05,
421
CLAMP60/25
421
CLAMP60/25MM, Replaced By: N000000006126
421
CLAMP60/25RSGU
469
TEMPERATURE SENSOR RETARDER TEMPERATURE
475
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 60-80X13 MM
475
CLAMP CONNECTION OF COOLING WATER LINES 55-75X13MM
484
SCREWM 10X20
487
NUT , Replaced By: N913023010002
490
SCREW. HEXAGON HEAD BOLT BRACKET MOUNTING M14X1.5X25,V 207570
490
SCREW PICK-UP PLATE BRACKET ON LONGITUDINAL MEMBER M 14X25
493
SCREW BRACKET TO SIDE MEMBER M10X35
496
HEXAGON HEAD BOLTM8X85
496
HEXAGON HEAD BOLTM8X90
496
HEXAGON HEAD BOLT. SCREW BRACKET MOUNTING M8 X 30
499
WASHER PUMP TO CONSOLE
