Поз.
Артикул
Описание
5
SHIM STEERING TO FRAME
5
PLATE STEERING TO FRAME
8
SCREW STRUTS TO SIDE MEMBER WITH ANGLE
11
WASHER , Replaced By: N000125013008
11
WASHER FLEXIBLE DISC TO PROPELLER SHAFT
14
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
14
NUT , Replaced By: N910113012003
17
HOSE DELIVERY LINE
17
HOSE DELIVERY LINE
21
BUFFER. RUBBER RING PROTECTION AGAINST SCORING FOR HOSE
29
HOSE (RETURN LINE),FROM STEERING TO OIL TANK
29
HOSE , Replaced By: A0009974752
32
GLAND , Replaced By: A0019901967
32
SEAL CONE LINE CONNECTION
35
UNION NUT LINE CONNECTION, Replaced By: N000000006239
35
UNION NUT LINE CONNECTION
38
HOSE (RETURN LINE),FROM STEERING TO OIL TANK
38
HOSE RETURN LINE
44
LINE COOLING LINE
50
LINE COOLING LINE
53
HOSE (RETURN LINE),FROM STEERING TO OIL TANK
59
HOSE CLAMP LINE MOUNTING
59
CLAMP , Replaced By: A0059970190
62
SCREW PUMP TO BRACKET
65
WASHER COVERING TO CAB
68
WASHER COMPRESSED AIR LINE TO BRACKET
71
NUT SPRING-LOADED PUSH ROD
74
NUT RETAINER , Replaced By: A3229900091
74
NUT RETAINER , Replaced By: A0009907191
999
LINE COOLING LINE, NOT USED
