Mercedes A6296251114 - HALTER MI

S 416 HDH MODELLPFLEGE 629.625

62 COWL,FRONT PANEL - 030 FRONT PANEL IL. 2

Поз.
Артикул
Описание
140
A6296270008
COVERING
143
A6296201814
BRACKET
146
A6296200715
CONSOLE
149
A6296251014
BRACKET , Replaced By: A6296251114
152
A6296250914
BRACKET
155
A6296251114
BRACKET , Replaced By: A6296254514
158
A6296200815
CONSOLE
161
A0009871762
RUBBER SECTION BLACK PVC, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
164
N910105008013
SCREW PIPE ELBOW TO BRACKET M8X12
167
N910105006004
SCREW , Replaced By: N914146006102
167
N910143006001
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
170
N910112008000
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
173
N910112006001
NUT , Replaced By: N913023006001
176
N910105008026
SCREW BRACKET TO CAB REAR PANEL M 8X20
179
A6296280200
GUMMED LABEL
