Поз.
Артикул
Описание
5
SOLENOID VALVE 3/2-WAY VALVE ADBLUE
8
VALVE (3/2-WAY SOLENOID VALVE)
11
SCREWM6X12 TX30
14
SEAL RINGBOSCH
17
VALVE (OVERFLOW VALVE) WABCO
20
VALVE PRESSURE LIMIT VALVE
29
BRACKET VALVE UNIT
32
SCREWM 10X20
35
SCREW , Replaced By: N910143008009
35
HEXALOBULAR BOLT TRAVEL SENSOR TO FRAME SIDE MEMBER M8X70,V 207570
38
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
41
HEXALOBULAR BOLT. SCREW , Replaced By: N910105008024
41
SCREW. HEXAGON HEAD BOLT FRONT EXHAUST PIPE TO MUFFLER M8X110 - TO A 979 492 03 40
44
SPACER WASHER AT CONSOLE
47
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
50
RESERVOIR
53
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
56
VALVE DRAIN VALVE
59
SEAL RING20.3X2.4
62
THRUST RING CHECK VALVE TO AIR RESERVOIR
65
CHECK VALVE
71
LINED6
71
LINE
71
LINE8MM
74
UNION NUT. NUTM12X1,5, Replaced By: N915017006100
74
UNION NUT
77
GLANDBS6
80
CONNECTION PIECE COMPRESSED-AIR-LINE PLUG-CONNECTION TO M10, 4MM, SDF
80
CONNECTION PIECE , Replaced By: A0049971489
83
PLASTIC PIPE RISING PIPE 4X6 MM
86
PLASTIC PIPE AERATION, ORDER BY THE METER
89
SEAL RING 3/2-WAY VALVE
104
FITTING6X1/M16X1.5 RAUFOSS
119
FITTING8X1/M16X1.5 RAUFOSS
120
FITTING8X1/M22X1.5 RAUFOSS
131
ELBOW FITTINGP5/6X1/90GR RAUFOSS
134
ELBOW FITTINGP5/8X1MM/90GR
141
FITTINGP5/M10X1 RAUFOSS
146
FITTINGP5/M12X1.5 RAUFOSS
148
FITTINGP5/M16X1.5
149
FITTINGP5/M22X1.5 RAUFOSS
161
FITTINGM16X1.5/M16X1.5 RAUFOSS
166
FITTINGM16X1.5/M22X1.5/M16X1.5
176
FITTINGM12X1.5/M12X1.5
183
FITTINGM12X1.5/M10X1
184
FITTINGM16X1.5/M12X1.5 RAUFOSS
192
PLUG WITH O-RING M16X1.5
213
T-FITTINGM16X1.5/M16X1.5/P5 RAUFOSS
214
T-FITTINGM16X1.5/P5/M16X1.5 RAUFOSS
262
NUT WITH O-RING M16X1.5 RAUFOSS
263
NUT WITH O-RING M22X1.5 RAUFOSS
301
VALVE TEST VALVE M16X1.5/M16X1.5 RAUFOSS
400
BRACKET
403
BRACKET
406
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
409
NUT , Replaced By: N913023010002
412
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
412
CLAMPRSGU S 18/15
415
SCREW BRACKET AND CLAMP M6X20
421
CABLE STRAP7.8X465
