Поз.
Артикул
Описание
5
STRIKER
8
HEXALOBULAR BOLTM8X16
29
SWITCH
29
SOLENOID SWITCH
32
TAPPING SCREW. SCREW FASTENING SOLONOID SWITCH 3.5X32MM
35
MAGNET
38
SCREW. TAPPING SCREW4,2X38 MM
40
WASHER PLASTIC
41
TAPPING SCREW3,5X13
41
TAPPING SCREW3.5X16
41
TAPPING SCREW3,5X16MM
43
DOOR INNER PANEL
44
FRAME
44
DOOR FRAME CENTRAL LEFT 1380UL
44
FRAME CENTRAL LEFT 1380UL, Replaced By: A6337301208
44
FRAME CENTRAL RIGHT 1380UL, Replaced By: A6337301308
44
DOOR FRAME CENTRAL RIGHT 1380UL
44
DOOR FRAME900UL
45
RIVETED NUT
47
PANELLING DOUBLE DOOR:
47
PANELLING
50
PANELLING
50
PANELLING
51
DOOR PANELING
53
GLASS PANE DOUBLE DOOR: 1380UL
55
FIXED GLASS PANE
56
WEATHERSTRIP900UL
56
WEATHERSTRIP CENTRAL LEFT 1380UL
56
WEATHERSTRIP CENTRAL RIGHT 1380UL
59
LEDGE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
59
LEDGE , Replaced By: A6327220065
61
PANELLING. CAP CENTRAL RIGHT
61
PANELLING CENTRAL LEFT
62
TAPPING SCREW3,5X13
62
TAPPING SCREW3.5X22
62
TAPPING SCREW3.5X16
62
TAPPING SCREW3,5X16MM
63
RUBBER STRIP6X15X20
65
LATCH
68
PLATE
71
NUT
74
PAD
98
DOOR INSIDE FRAME DOUBLE DOOR: 1380UL
98
DOOR INSIDE FRAME900UL
108
TAPPING SCREW3,5X16MM
110
LEDGE
171
BLIND RIVET4X8
173
DOOR HANDLE WITHOUT FUNCTION BAR
179
NUTM5
179
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
188
SLIDE
191
SCREWM6X12 TX30
191
SCREWM6X20
191
SCREWM6X20 T30
210
STOP PLATE
245
ADHESIVE TAPE4.5X10 MM, ORDER BY THE METER
245
SOFT STRAP. BAND ADHESIVE FASTENER, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
245
ADHESIVE TAPE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
245
HOOK STRAP. BAND ADHESIVE FASTENER, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
245
ADHESIVE TAPE BETWEEN PANE AND DOOR WING 6000 MM
245
ADHESIVE TAPE3900 MM
246
FOAM PLASTICS POLYETHYLENE, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
247
PANELLING RIGHT 1380UL
247
PANELLING LEFT 1380UL
248
DOOR INTERIOR TRIM LEFT
248
DOOR INTERIOR TRIM RIGHT
250
PANELLING LEFT 1380UL
250
PANELLING RIGHT 1380UL
253
PLATE RIGHT
253
PLATE LEFT
265
INSULATION496X63X20
265
INSULATION20X500X1000MM
268
INSULATION496X295X3
268
INSULATION30X500X1000MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
271
INSULATION30X500X1000MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
271
INSULATION
274
INSULATION496X500X3
274
INSULATION30X500X1000MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
CLEANER
