Поз.
Артикул
Описание
5
FUEL TANK LEFT NOWOTECH
5
FUEL TANK LEFT
8
FUEL TANK RIGHT NOWOTECH
8
FUEL TANK RIGHT
17
PRESSURE RELIEF VALVE , FROM 01.07.09
20
SCREW PLUG
20
SCREW PLUGM18X1.5 NOWOTECH
23
SEAL RING SOLENOID VALVE A 18X24
26
STRAP LEFT 1705MM
29
STRAP RIGHT 1870MM
32
ADHESIVE STRIP. BASE40 X 2 MM
35
RUBBER STRIP
38
CLAMP
41
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
44
NUT
47
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
50
CLAMP OIL LINE TO BRACKET
50
CLAMP48/20
53
SENDER UNIT
56
TAPPING SCREW MOUNTING PARTS 4.8X16
59
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
62
HOSE (SHUT OFF COCK), ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
62
HOSE940MM, Replaced By: A0014760426
65
LINE7,5X3, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
68
CLAMP10-16X9MM
71
LOOM TIE
74
FILLER CAP
77
SEAL RING TO FILLER CAP
80
RETENTION CHAIN TO FILLER CAP
100
TANK
103
SCREW PLUG , Replaced By: N007604018101
106
SEAL RING VALVE TO VALVE,K 025179
109
SCREW PLUG FUEL TANK
112
SEALING RING. SEAL RING ENGINE BREATHING
115
SENDER UNIT
118
FILLER CAP
121
STRAP
124
RUBBER STRIP
127
ADHESIVE STRIP. BASE40 X 2 MM
130
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
133
BRACKET FUEL OIL TANK
136
NUT HORN TO BRACKET M8
139
SCREW BRACKET TO CAB REAR PANEL M 8X20
