Поз.
Артикул
Описание
5
PROTECTIVE PLATE ENGINE PROTECTIVE PLATE
8
MOUNTING ANGLE LEFT
11
MOUNTING ANGLE RIGHT
14
SCREW , Replaced By: N304017008034
14
SCREW BRACKET TO CROSS CONNECTION STRUT
17
NUT SWITCH TO FLOOR PLATE
20
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
23
WASHER , Replaced By: N000125010532
23
WASHER RADIATOR TO RUBBER MOUNTING
26
NUT AIR CLEANER ELEMENT
29
PROTECTIVE PLATE LEFT
29
PROTECTIVE PLATE LEFT
32
PROTECTIVE PLATE RIGHT
32
PROTECTIVE PLATE RIGHT
35
RUBBER SEALSA 28400/02
35
RUBBER SEAL , Replaced By: A4619870151
38
RIVET
38
RIVETB 4X11X12
41
PROTECTIVE PLATE REAR LEFT
41
PROTECTIVE PLATE REAR RIGHT
44
PROTECTIVE PLATE FRONT
47
SCREW PUMP TO BRACKET
50
WASHER COMPRESSED AIR LINE TO BRACKET
50
WASHER , Replaced By: N009021006208
53
RUBBER SEAL , ORDER BY THE METER
59
PROTECTIVE PLATE FRONT
