Поз.
Артикул
Описание
11
PIPE SOCKET WATER DRAIN
13
SEAL
15
SWITCH
16
ELEKTROKOCHER SAUSAGE COOKER VST
16
ELEKTROKOCHER SAUSAGE COOKER VST
16
HOT PLATE SAUSAGE COOKER BEHAELTER MIT HEIZUNG
16
ELECTRIC COOKER SAUSAGE COOKER, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 13.10.2006 UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 30.04.2008
16
COOKER SAUSAGE COOKER, UP TO IDENT NO. WEB 102744 EXCEPT FOR WEB 102753 , WEB 102787 , WEB 102804
16
COOKER SAUSAGE COOKER, FROM IDENT NO. WEB 102745 ALSO INSTALLED ON WEB 102753 , WEB 102787 , WEB 102804
18
COVERING WITH GASKET, Replaced By: A0008400036
18
COVER FOR COOKER WITH GASKET
20
BRACKET FOR SAUSAGE COOKER COVER
22
TUBE1/2",150MM
24
SEAL RING12,37X2,62MM
28
KNOB BLUE
28
KNOB RED
29
VALVE
30
GASKET
31
MIXING FAUCET
32
PIPE SOCKET
33
WATER FAUCET
33
DISCHARGE
34
TEMPERATURE SENSOR CENTRAL
56
STRIKER PLATE
58
HOUSINGSCHRANK-GEHAEUSE GROSS
58
DRAWER COMPARTMENTSCHRANK GEHAEUSE KLEIN
64
SWITCH
70
RELAY
70
RELAY
70
RELAY40A
70
RELAY50A
72
SOLENOID VALVE PLASTIC 24 VDC
84
LIGHT EMITTING DIODE
84
BULB24V/5W
86
SOCKET
86
INTERIOR LAMP
97
COFFEE MACHINEMOD.05(40T), FROM IDENT NO. WEB 102745 ALSO INSTALLED ON WEB 102753 , WEB 102787 , WEB 102804
164
SEAL RING
169
PLUG
170
ROOF RACK
170
LUGGAGE NET
172
CONTAINER WATER RESERVOIR
173
LEVEL SWITCH
174
COOKER HEATING ELEMENT
176
MOUNTING RING
178
SEAL RING
190
HOUSING ASHTRAY
190
ASHTRAY
195
CONNECTION FITTING
196
PIPE SOCKET
197
DISCHARGE FITTING
208
DRAWER MAJOR, Replaced By: A0008401902
208
DRAWER MAJOR
208
DRAWER MINOR
210
COVERING , FROM IDENT NO. WEB 102745 ALSO INSTALLED ON WEB 102753 , WEB 102787 , WEB 102804
210
COVERING
212
BRACKET
216
FLAP
226
THERMOS
226
THERMOS BOTTLE , Replaced By: A0008453423, +001A0008450324
227
BRACKET
228
LEDGE
229
SETTING DIAL
230
WASHER
231
DETENT
232
SPRING
233
CLAMP
234
PLATE
235
WATER FAUCET
236
SHEET BARS
237
OPERATING UNIT
237
ELECTRICAL UNIT OPERATING UNIT
999
CABLE HARNESS
999
CABLE HARNESS , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.02.2007
999
COVER
999
COVERING ASHTRAY
999
CABLE HARNESS
999
CLUTCH
999
BOILER
999
CONTINUOUS-FLOW HEATER
999
CONTINUOUS-FLOW HEATER
999
BOILERVST
999
BOILER
999
HEATING ELEMENT
999
TEMPERATURE SENSOR
999
PLATE
999
FITTING ELBOW FITTING
999
HINGE
999
TAKE-UP DEVICE
999
COVERING
999
CUP HOLDER
999
CUP DISPENSER
999
BRACKET
999
HINGE
999
VALVE
999
WATER LINE
999
VALVE
999
BRACKET LEFT
999
GASKET , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.02.2007
999
CONTAINER
999
CONTAINER WATER RESERVOIR
999
FITTING
999
FITTING
999
FITTING
999
THERMAL FUSE
999
CLIP
999
PIPE SECTIONPVC GERADE30 X 1,5 X 200
999
PIPE SECTIONPVC GERADE30 X 1,5 X 660
999
WASHER
999
THROTTLE
999
SEAL CONE
999
FITTING
999
INTERIOR LAMP
999
CASE. PLUG HOUSING
999
CASE. PLUG HOUSING
999
HOSE SILICONE, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
WELT , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
MOUNTING CLIP MOUNTING, LUGGAGE NET
999
T-FITTING
999
CONNECTOR
999
CABLE HARNESS
999
CONTROL UNIT CENTRAL LUBRICATION
999
CONTROL UNIT
999
COUPLING
999
SWITCH
999
ELECTRIC CABLE
999
CLIP
999
COVER
999
HOUSING
999
KITCHENETTE
999
KITCHENETTE
999
WASHER
