Поз.
Артикул
Описание
200
COOLANT LINE FEED 1130MM, UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 20.06.2010
203
REFRIGERANT LINE FEED
206
VALVE TWO-WAY ALCO
209
SLEEVE10MM
212
REFRIGERANT LINE RETURN, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.10.2010
212
REFRIGERANT LINE RETURN 740MM, UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 20.06.2010
215
COOLANT LINE. PIPE LINE9700MM
218
REFRIGERANT LINED10/6500MM
221
REFRIGERANT LINE RETURN
224
T-FITTING
227
INTERMEDIATE PIECE
230
REFRIGERANT LINE FEED
233
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 25/15 MM
233
MOUNTING CLAMP22/15
233
CLAMP10/15
233
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
233
CLAMP22/15, Replaced By: A0019951442
233
CLAMP COMPRESSED AIR LINE TO TRANSMISSION COVER 25/15
239
SCREW BRACKET AND CLAMP M6X20
242
NUT , Replaced By: N913023006001
245
BUSHING
999
PLATE
999
BLIND RIVET BRACKET TO BRACKET 3.2X8
