Поз.
Артикул
Описание
32
SUPPORT. SPRING BRACKET
35
SUPPORT. SPRING BRACKET
38
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
41
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
41
NUT SUPPORT TO FRAME
56
WOODRUFF KEY TOP PLATE TO CROSS MEMBER
59
LOCK AT CROSS MEMBER
62
NUT POWER CYLINDER TO BRACKET
62
NUTM24X1.5-14H
62
NUT TOP PLATE TO FRONT AXLE CROSS MEMBER
65
SUPPORT FRONT AXLE AIR SPRING BELLOWS
65
SUPPORT AIR SPRING BELLOWS,BOTTOM
65
PISTON
68
BELLOWS. BOOT
68
AIR SPRING BELLOWSBL121
68
AIR SPRING BELLOWS TRAILING AXLE LIFT
68
AIR SPRING BELLOWS REAR AXLE
110
HEXAGON HEAD BOLTM16X1.5X110
125
SHOCK ABSORBER COMPLETE NV36X240HAZF-SACHS
125
SHOCK ABSORBER
128
RETAINER
131
BUSHING , Replaced By: A0003232750
134
BUSHING BOTTOM, ON VEHICLES HAVING NO MERCEDES BENZ BODY UP TO IDENT NO. 097835, 628.000.10.300181, 628.000.14.172140 FOR USE WITH MERCEDES-BENZ BODY UP TO IDENT NO.: 097975 EXCEPT FOR 096942,097122-097130,097138,097412,097413,097453,097470,097471,097514-097532,097534,097544-097549, 097575-097589,097761-097773,097916-097920.
137
RETAINER
140
RUBBER BUFFER , Replaced By: A0003234185
143
RETAINER
146
NUT , Replaced By: N913004014005
149
DUST CAP
152
SUPPORT FRONT
155
SUPPORT REAR
158
SCREW. HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X40
161
SCREW. HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X40
164
HEXAGON HEAD BOLT AT FRAME, REAR M16X1.5X40
167
NUT FIFTH WHEEL COUPLING TO MOUNTING PLATE M16X1.5
176
PLATED 132.5
179
PLATE AIR SPRING BELLOWS TO SUBSTRUCTURE,082398 ALSO INSTLLED ON 061787,079341 EXCEPT FOR 082399
179
PLATE , Replaced By: A6183200135
179
PLATE ,WEB 629012 13 520210,WEB 629015 13 520032
