Поз.
Артикул
Описание
8
PLASTIC PIPE AERATION, ORDER BY THE METER
14
HOSE DELIVERY LINE TO POWER CYLINDER
23
3-2-WAY PNEUMATIC VALVE (3/2-WAY SOLENOID VALVE)
23
SOLENOID VALVE (3/2-WAY SOLENOID VALVE)
26
SCREWM6X12 TX30
29
SEAL RINGBOSCH
32
REDUCTION FITTINGM14X1.5/M12X1.5
32
FITTING PARKING BRAKE VALVE,CONNECTION: "23"
35
FITTING FROM PUMP TO CYLINDER
35
ELBOW FITTINGL6
44
ELBOW FITTING
65
HEXALOBULAR BOLT SOLENOID VALVE TO BRACKET M8X100
68
NUT ENGINE MOUNTING M8
68
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
71
CLAMP SUCTION/DELIVERY/RETURN LINES 12/15MM
71
CLAMP LINE MOUNTING 8/15
71
CLAMP10/15
71
CLAMP38/20
71
CLAMP LINE MOUNTING
74
HEXALOBULAR BOLT. SCREW CLAMP ON BRACKET M 6X35
74
HEXALOBULAR BOLT GROUND CABLE TO GENERATOR M6X20
77
NUT , Replaced By: N913023006001
403
BRACKET
412
CUTTING RINGBS8
415
NUTM 14 X 1,5AL
418
GLAND
421
UNION NUT
430
PIPE10X1
430
LINE10MM
433
PIPE8MM
433
LINE8MM
499
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
505
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
508
FITTING AT T-FITTING M16X1.5
511
FITTING RELAY VALVE,CONNECTION: "40",5 359430
514
FITTING BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
517
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
520
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
523
SEAL RING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTIONS: "22"
