Поз.
Артикул
Описание
5
UREA CONTAINER
50
PUMP MODULE , Replaced By: A0001402578
100
STRAP
220
SOLENOID VALVE. VALVE
240
COUPLING
242
CONNECTOR12-90GRAD
244
PLUG CONNECTOR HEATING WATER CONNECTION 90 GRAD, TO 000 140 02 78
280
GROMMET
280
STOP CLUTCH PEDAL STOP
280
GROMMET
290
ADHESIVE STRIP. BASE40 X 2 MM
292
RUBBER STRIP
294
RUBBER PROFILE BLACK, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
300
SPACER SLEEVE. SPACER TUBE VALVE TO CRANKCASE
320
BRACKET ,WKK 629410 13 102802, Replaced By: A0004700781
325
SUPPORT
400
HOSE271-15X24X2000, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
402
RADIATOR HOSE9X3.5 MM, ORDER BY THE METER
404
FUEL HOSE. HOSEB5,5-2,5,WEB 629012 13 520122 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
430
LINE
432
SUCTION LINE
434
RISING PIPE
460
PROTECTIVE PLATE
606
NUT BRACKET TO FIRE WALL
606
NUT , Replaced By: N913023006001
608
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
608
NUT HORN TO BRACKET M8
610
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
696
LOCK NUT. SPRING NUT MOUNTING PARTS
706
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
706
SCREW , Replaced By: N914146006102
708
SCREWM6X65
708
SCREW , Replaced By: N910143008000
710
SCREW BRACKET TO SIDE MEMBER M10X35
710
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
800
CLAMP
810
CLAMP10/15
810
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
815
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
822
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
827
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
900
LOOM TIE
900
CABLE TIE , Replaced By: A0049971890
999
FITTING ADBLUE OUTPUT
999
REPAIR KIT O-RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10, SDF
