Поз.
Артикул
Описание
10
PANELLING
12
ANGLE
16
SCREW FUSE BOX TO SIDE MEMBER,5 097182
18
WASHER LINE MOUNTING
80
COVERING DEEP FREEZER
90
PANELLING
150
FLAP
180
COVERING
185
TRIM PANEL CENTER CONSOLE
231
BRACKET
234
BRACKET
237
BRACKET
240
BRACKET
243
BRACKET
247
BRACKET
249
SNAP LOCK
260
SHEET METAL SCREW MODULE TO HOUSING
263
SHEET METAL SCREW BRACKET TO FLOOR PLATE
269
HEXALOBULAR BOLT FASTENING RADIO SET 4X12
378
TRIM PANEL FEET RECESS LEG ROOM
381
CAP COVERING
382
SPRING
383
WASHER
384
FASTENER WITH EYELET
385
FASTENER BUTTON
600
COVER CAP
814
BRACKET
832
FEED-THROUGH GROMMET
834
BORDER RING
836
BELLOWS LANE DEPARTURE WARNING SYSTEM, TO BE ADAPTED DURING ASSEMBLY
838
BRACKET PANORAMIC CAMERA
840
FEED-THROUGH GROMMET
842
INSULATING HOSE FLEXIBLE, FOR CABLE HARNESS DIA.: 7.5 MM, ORDER BY THE METER
844
COVERING RAIN/LIGHT SENSOR
902
BOLT. SCREWM4X10 T20
924
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION
930
TAPPING SCREW MOUNTING PLATE 3.5X9.5
990
FELT STRIP SELF-ADHESIVE 15X1MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
