Mercedes A0006830006 - MONTAGERAHMEN

TRAVEGO RHD-L 632.247

68 PANELLING AND LINING - 270 FLOORING,FLOOR FLAPS IL. 5

Поз.
Артикул
Описание
59
A6326800458
RECESS , Replaced By: A6326800658
59
A6326800058
SHEET-METAL PAN
62
A6326840364
FLOOR FLAP
62
A6326843264
FLOOR FLAP , TO BE ADAPTED DURING ASSEMBLY
65
A0009883063
SNAP LOCK
68
A0006840152
HINGE STRAP32X0.7-3550MM, TO BE ADAPTED DURING ASSEMBLY
71
A6296801607
CLOSING COVER
72
A0009980695
ROTARY CATCH
73
A0009980595
ROTARY CATCH
77
A6326870107
COVERING , UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 31.05.2009
150
A6326860307
COVER
164
A0006800323
SERVICING COVER
167
A0006830006
FRAME
303
A6296860407
COVERING CROSS MEMBER 4
306
A6326840877
COVER
309
A6326840977
COVER
312
A6326820816
COVER ELECTRICAL COMPARTMENT
315
A6326820916
COVER ELECTRICAL COMPARTMENT
318
A6326841177
COVER WATER PIPES
