Поз.
Артикул
Описание
11
COVER
107
BUFFER WASHROOM DOOR
108
MOUNTING
110
SWITCH WASHROOM DOOR
113
SWITCH DOOR LOCK
116
STOP DOOR STOP
119
CAP PLASTIC
122
MORTISE LOCK. FASTENER WASHROOM DOOR
125
DOOR HANDLE WASHROOM DOOR
125
DOOR HANDLE VACANT-OCCUPIED SET
128
RUBBER SECTION WASHROOM DOOR, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
129
RUBBER SECTION WASHROOM DOOR, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
131
SEAL
248
GASKET , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
251
SCREW BRACKET TO SIDE MEMBER M8X20
254
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
257
COVERING
260
TAPPING SCREW BRACKET TO CAB FLOOR 3.5X9.5
263
COVERING
266
SHEET METAL SCREW. SCREWST25X 6 T20
269
LOCKING CAP
272
FIXTURE
275
DRAIN WATER DRAIN
278
FLOOR , Replaced By: A0009837380
278
BOTTOM , Replaced By: A0009837380
278
PLYWOOD , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
287
ADHESIVE STRIP. BASE40 X 2 MM
290
TAPPING SCREW BRACKET MOUNTING 3.5X25
299
CAP GRIP RAIL
311
COVERING
332
W.C. DOOR. W.C. DOORRHD, DETERMINE COVER FABRIC VIA VEDOC "NFC 5117"
446
FITTING
461
FASTENER MECHANICAL
461
FASTENER PNEUMATICALLY CONTROLLED
461
LOCK LAVATORY DOOR MECHANICAL
461
LOCK PNEUMATICALLY CONTROLLED
512
EDGE TRIMALU, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
515
PLASTIC SECTION , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
518
LEDGE
521
TAPPING SCREW3.5X19
521
TAPPING SCREW AT BRACKET 2.9X9.5
536
SMOKE DETECTORORS 142
539
SMOKE DETECTOR SOCKET TO BODY
542
SEAL
545
SCREEN
548
FITTING
551
HOSE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
554
CLAMP44 - 60/9
566
SQUARE KEY WASHROOM DOOR
581
COVERINGH - PROFIL, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
583
SHELL PUSH BUTTON SWITCHES
585
COVERBLENDE GELB
587
EMERGENCY SWITCH RED
589
STICKERALARM/NOTRUF
591
STICKERSOS
999
SEAL
999
COVER
999
SHAPED SECTIONPVCH - PROFIL GEBOGEN
999
SPIRAL SPRING
999
COMPRESSED AIR LINE
999
PLUG SOCKET
999
SOCKET-OUTLET220 V
999
FASTENER
999
LAVATORY TOILET CABIN
999
LAVATORY TOILET CABIN
999
LAVATORY TOILET CABIN
999
LAVATORY TOILET CABIN
