Поз.
Артикул
Описание
5
GUIDE RAIL A-PILLAR
8
8
11
WINDOW GUIDE TOP
11
WINDOW GUIDE TOP, Replaced By: A6337250530
14
ANGLE
20
TAPPING SCREW RAIL
20
TAPPING SCREW MOUNTING PLATE 3.5X9.5
23
26
BLIND RIVET
29
GUIDE RAIL
32
WINDOW RUBBER RUNL4300MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
44
SEALING FRAME
44
SEALING FRAME
47
NUTM4
50
HEXALOBULAR BOLT FASTENING RADIO SET 4X12
50
HEXALOBULAR BOLT. SCREW
53
SEAL INSIDE
56
59
RUBBER SECTION848LG, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
62
GLASS PANE
63
WINDOW REGULATOR ELECTRIC
63
WINDOW REGULATOR ELECTRIC, Replaced By: A0007251102
64
WINDOW REGULATOR
65
ELECTRIC MOTOR WITH TRANSMISSION TO A 628 820 00 42
65
ELECTRIC MOTORTO A 000 725 11 02
66
INTERFERENCE SUPPRESSOR
67
PLUG CONECTION
68
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
71
RETAINING RAIL
74
HEXAGON HEAD BOLT
75
SCREW BRACKET AND CLAMP M6X20
77
NUT , Replaced By: N913023006001
80
CAPTIVE NUTM6
83
SEALING RAIL BOTTOM
83
SEALING RAIL BOTTOM
86
WASHER BRACKET TO BATTERY CASE BRACKET
89
HOSE
92
RUBBER STRIPL5200MM
95
SOLENOID SWITCH
98
ANGLE
98
ANGLE , Replaced By: A6337250212
101
PROFILE SEAL , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
104
SPACER35X12X4MM
