Mercedes A0029908022 - Болт

INTEGRO M 633.002

71 PARTITION PANEL - 180 GRIP RAILS AND PARTITION PANELS IL. 18

Поз.
Артикул
Описание
601
A6298101132
CLAMP , TO BE ADAPTED DURING ASSEMBLY
604
A6329100071
HANDLE
605
A6329190120
COVERING
610
A6277117234
CONNECTION , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
613
N910112008000
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
629
A6277100432
CONNECTIONGR90
632
A6277103732
CONNECTIONGR45
635
A0009972876
CONNECTION
638
N910105008045
SCREW. HEXAGON HEAD BOLT GGVS-COMPONENT IN BATTERY CARRIER M8X55
641
N000000001432
HEXALOBULAR BOLT ABSORBER AT BOTTOM TO INTEGRAL CARRIER AT LEFT AND RIGHT
644
A0029908022
BOLT. SCREWM8X30MM
999
A3093260353
SPACER TUBE
999
A6298130028
CLIP
