Поз.
Артикул
Описание
5
COOLANT LINE COMPLETE
8
COOLANT LINED22/1900MM
11
COOLANT LINED22/1970MM
14
COOLANT LINED22/2300MM
17
COOLANT LINED28/2400MM
20
COOLANT LINED28/1980MM
23
COOLANT LINED28/1900MM
26
PIPE LINE. COOLANT LINED28/1150MM
29
REFRIGERANT LINED10MM/2500MM
32
SEAL RING7.5X2
35
REFRIGERANT LINED10MM,3750MM
35
REFRIGERANT LINED10MM/4050MM
38
COOLANT LINED10MM/2090MM
41
REFRIGERANT LINED10/1700MM
44
COOLANT LINE1500MM,BEHR
44
REFRIGERANT LINESPHEROS/10X1500MM
47
SEAL RING7.5X2
47
SEAL RING HOSE TO EXPANSION VALVE 7.5 MM
50
COOLANT LINED16/2300MM,BEHR
50
COOLANT LINED16/2300MM,SPHEROS
53
SEAL RING HOSE TO CONDENSER 14 MM
53
O-RING HOSE TO EXPANSION VALVE 17X2
56
COOLANT LINED16MM/8725MM
59
COOLANT LINED16/2100MM
62
GASKET34X42 MM
68
GROMMET
71
GROMMET
74
BUSHING
77
BRACKET
80
CLAMP10/15
80
CLAMP , Replaced By: N916016010211
80
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
83
CLAMP , Replaced By: N916016015202
83
CLAMP16/15, Replaced By: A0019950842
83
MOUNTING CLAMP16/15
86
MOUNTING CLAMP22/15
86
CLAMP DELIVERY AND SUCTION LINES TO FRAME
86
CLAMP22/15, Replaced By: A0019951442
89
CLAMP HOSE TO FLANGE AND TO VALVE
89
CLAMP COMPRESSED AIR LINE TO TRANSMISSION COVER 25/15
89
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 25/15 MM
92
MOUNTING CLAMP28/15
92
CLAMP CABLE HARNESS MOUNTING
92
CLAMP28/15, Replaced By: A0019951842
95
CLAMP COOLING WATER HOSES
95
CLAMP35/20, Replaced By: N000000007514
95
CLAMP35/20
98
SCREW BRACKET AND CLAMP M6X20
101
SCREW , Replaced By: N910143008002
104
SCREW PIPE ELBOW TO CHARGING AIR INTERCOOLER M 10X35,5 708090
107
CAP BOLT. SCREW BELT TIGHTENER TO SUPPORT M10X50,*0211352
110
SCREW AXLE HOUSING TO REAR SUBFRAME,FRONT
113
NUT , Replaced By: N913023006001
116
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
119
NUT , Replaced By: N913023010002
122
LOCK NUT. SPRING NUT MOUNTING PARTS
125
NUTM8
128
CABLE TIE310X5MM
131
PLATE
134
BLIND RIVET BRACKET TO BRACKET 3.2X8
137
HOSENW25
140
HOSE. REFRIGERANT LINENW20
