Поз.
Артикул
Описание
35
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
74
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
77
SCREW BRACKET TO SIDE MEMBER M8X20
80
NUTM8
86
SCREW SPEED SENSOR TO REAR AXLE
119
SEALING STRIP , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
122
FRAME
125
MUFFLER
128
LOCK LEFT
131
LOCK RIGHT
134
STRIKER
137
CLIP
140
SLEEVE
143
CLAMP
146
HINGE BASE FRAME
149
RETAINING STRAP
152
RETAINING STRAP. BRACKET
155
BRACKET
158
BRACKET RIGHT CENTRAL
161
BRACKET BUMPER PANELLING,LEFT
176
SCREW 3/2-WAY VALVE TO BRACKET
179
TUBE
185
CYLINDRICAL HEAD SCREW. SCREW HOUSING,TOP M6X30
188
BRACKET WATER RESERVOIR
191
BRACKET WATER RESERVOIR
194
PIN
197
CLAMPING DISC
200
LOCK RING PUSH ROD TO PEDAL
203
ROLL PIN
206
LEVER
209
SLEEVE
212
WASHER BRACKET TO FUEL TANK SUPPORT
215
ROD
218
PLATE
221
SPRING
224
STRAP
227
STRAP
230
NIPPLE
233
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
236
NUT RELAY TO BRACKET M5
239
NUT-AND-WASHER ASSEMBLY ANTENNA AT BRACKET M4
242
WASHER COMPRESSED AIR LINE TO BRACKET
245
LOCK
248
WASHER BRACKET TO CAB REAR PANEL
999
SCREW. HEXAL. SOCKET CSK. BOLTM8X30
999
DAMPING DISK
