Поз.
Артикул
Описание
8
BELLOWS. BOOT
8
AIR SPRING BELLOWS4644N
11
HELPER SPRINGHOEHE 80, Replaced By: A6283210007
11
RUBBER BUFFER
14
PISTON
17
LOCKING CAP
17
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
20
NUTM24X1.5-14H
20
NUT POWER CYLINDER TO BRACKET
23
SHOCK ABSORBER COMPLETE NV36X220HA
23
SHOCK ABSORBER COMPLETE
26
RETAINER
29
RUBBER MOUNTING
32
BUSHING TOP TO 673 323 00 00,675 323 06 00
35
RETAINER
38
RETAINER SHOCK ABSORBER MOUNTING,FRONT,067210079427
41
NUT , Replaced By: N913004014005
44
DUST CAP
47
CONTROL ARML570MM
47
RADIUS ROD (LONGITUDINAL CONTROL ARMS) TOP, ON VEHICLES HAVING NO MERCEDES BENZ BODY FROM IDENT NO. 097836 , 628.000.10.300182, 628.000.14.172141 FOR USE WITH MERCEDES-BENZ BODY FROM IDENT NO. 097976 ALSO INSTALLED ON 300175-300180.
47
CONTROL ARML570MM,WEB 629012 13 520017, Replaced By: A6283331705
50
CONTROL ARML658MM,WEB 629012 13 520017, Replaced By: A6283331805
50
RADIUS ROD (LONGITUDINAL CONTROL ARMS) BOTTOM
50
CONTROL ARML658MM,WEB 629012 13 520017
53
REPAIR KIT
56
SCREW TOP TRAILING ARM ON AXLE BEAM M18 X 1.5 X 60 MM
59
HEXAGON HEAD BOLT CROSS MEMBER TO SUPPORT M18X1.5X140
59
SCREWM18X1.5X14010.9
62
WASHER3X35X50
62
WASHER2X35X50
62
WASHER5X35X50
65
NUT TRAILER COUPLING TO FRONT CROSS MEMBER M18X1.5
68
HEXAGON HEAD BOLT SUPPORT TO SIDE MEMBER M18X1.5X130
71
STUD BOLT BELLOWS ON BRACKET
71
SCREW BELLOWS ON BRACKET
74
PLATED 80X15
77
PLATE
86
CENTERING DISCHOEHE 23
89
SCREW
92
WASHER LONGITUDIAL CONTROL ARM, TOP, ON SUBSTRUCTURE 5 MM
92
WASHER LONGITUDIAL CONTROL ARM, TOP, ON SUBSTRUCTURE 2 MM
92
WASHER LONGITUDIAL CONTROL ARM, TOP, ON SUBSTRUCTURE 3MM
92
WASHER LONGITUDIAL CONTROL ARM, TOP, ON SUBSTRUCTURE 4 MM
92
WASHER LONGITUDIAL CONTROL ARM, TOP, ON SUBSTRUCTURE 1MM
