Поз.
Артикул
Описание
5
PROTECTIVE PLATE
8
SCREW , Replaced By: N910143008000
11
NUTM8
14
METERING EQUIPMENT
14
METERING DEVICE , Replaced By: A0001400739
14
METERING EQUIPMENT , Replaced By: A0001404139
17
FILTER ADBLUE METERING DEVICE TO A000 140 05 78
20
NOZZLE HEATED
23
SEAL RING P.T.O. CONTROL
26
SCREW-IN FITTING. FITTING
26
FITTING , Replaced By: A0029977871
29
SEALING RING. SEAL RING
29
SEAL RING10X13,5MM
32
SCREW VALVE TO BRACKET M 8X60
35
BUSHING
38
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
41
FITTINGTO A 000 140 05 39
41
SCREW-IN FITTING. FITTINGTO A 000 140 07 39
44
SEAL RING10X13,5MM
44
SEALING RING. SEAL RINGTO A 000 140 05 39
47
DELIVERY LINE REDUCING AGENT
