Поз.
Артикул
Описание
100
JOINT REAR AXLE PNEUMATIC SUSPENSION
107
CYLINDER REAR AXLE PNEUMATIC SUSPENSION
108
VALVE (3/2-WAY SOLENOID VALVE)
112
BALL SOCKET , Replaced By: A3579910622
112
BALL SOCKET POWER CYLINDER TO LEVER
112
BALL SOCKET REAR AXLE PNEUMATIC SUSPENSION
112
CONICAL CUP (SOLENOID VALVE)
114
FITTING , Replaced By: A0089972572
114
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
116
CONNECTOR M10X1 (VOSS 230)
117
BUSHING LEVEL ADJUSTMENT VALVE TO BRACKET
118
SWITCH LOCKING VALVE,CONNECTIONS: "12"
121
T-FITTING FROM PRESSURE REGULATOR TO T-FITTING
123
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
124
NUT ENGINE MOUNTING M8
124
NUT HORN TO BRACKET M8
126
SCREW-IN FITTING , Replaced By: A0029978472
127
SEAL RING LINE CONNECTION
128
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
155
HEXAGON HEAD BOLT. SCREW SUSPENSION EYE AND BRACKET TO CYLINDER HEAD M 8X70,TO 366 223 06 41
155
SCREW , Replaced By: N910143008010
155
SCREW VALVE TO BRACKET M 8X60
158
NUT HORN TO BRACKET M8
158
NUT ENGINE MOUNTING M8
167
VALVE TRAILING AXLE SELF-LEVELLING DEVICE
167
VALVE DRIVING AXLE RIGHT
170
VALVE FRONT AXLE LEVEL ADJUSTMENT BOSCH
170
VALVE DRIVING AXLE LEFT
170
VALVE PNEUMATIC SUSPENSION BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
176
FILTER
179
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
182
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
185
FITTING TWO-WAY VALVE,CONNECTIONS: "1","2"
191
FITTING LINE CONNECTION
194
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 10, VOSS 232, Replaced By: A0009975034
194
SCREW. UNION SCREW , Replaced By: A0009973734
194
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
197
LOCK , Replaced By: A0009945448
200
SEAL RING , Replaced By: A0009940747
201
VALVE REAR AXLE LEVEL ADJUSTMENT VALVE
203
VALVE LEVEL ADJUSTMENT VALVE,CONNECTION: "10"
206
SCREW BRACKET TO CAB REAR PANEL M 8X20
230
ROD
230
ROD OPERATING ROD TO FRONT AXLE, ONLY APPLICABLETO 382.058: D 308941,D 313183,D 316393,D 316398,D 316403,D 316405,D 316411,D 316568,D 316572,D 316575,D 316580,D 316584,D 316588,D 316593, D 316596,D 316869,D 316870,D 316871,D 316873,D 316876,D 316878,D 316880,D 316882,D 316884,D 316886,D 316888,D 316890,D 316892.
230
ROD LEVEL ADJUSTMENT VALVE CONTROL
233
NUT HORN TO BRACKET M8
300
320
320
330
345
345
999
GUIDE SIGN VALVE TO CAB
