Поз.
Артикул
Описание
5
BRACKET ELECTRIC CABLE MOUNTING
8
BRACKET BRACKET TO LEFT SIDE MEMBER
8
9
BRACKET LEFT SIDE MEMBER,D 030553
9
BRACKET , Replaced By: A3812950440
9
BRACKET , Replaced By: A3464296040
10
11
BRACKET COMPRESSED AIR LINE TO SIDE MEMBER
12
SCREW BRACKET TO SIDE MEMBER M10X35
13
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
14
BRACKET FUEL LINE
14
BRACKET LINE MOUNTING
16
BRACKET COOLING WATER HOSES
16
BRACKET
17
BRACKET AT RIGHT SIDE MEMBER
19
20
BRACKET
21
BRACKET LINE MOUNTING
22
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
23
BRACKET COMPRESSED AIR LINE MOUNTING
25
NUT BRACKET TO FIRE WALL
26
29
BRACKET COMPRESSED AIR LINE TO SIDE MEMBER
32
32
BRACKET AT LEFT SIDE MEMBER
32
BRACKET TO MOUNT FUEL LINES
35
37
38
39
41
BRACKET LINE TO FRONT AXLE,LEFT
42
BRACKET LINE TO FRONT AXLE,RIGHT
43
BRACKET OIL LINE
43
46
BRACKET BATTERY CABLE
47
HEXAGON HEAD BOLT HEAT SHIELD MOUNTING M16X1.5X30
47
SCREW FRONT SPRINGS TO FRONT AXLE
50
HEXALOBULAR BOLT CONTROL LEVER TO PEDAL LEVER
53
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
53
SCREW VALVE TO BRACKET M 8X60
56
SCREW SHIFT LEVER TO BRACKET M8X30
59
SCREW BRACKET TO CAB REAR PANEL M 8X20
62
SCREW BRACKET TO CAB REAR PANEL M 8X20
62
SCREW SHIFT LEVER TO BRACKET M8X30
62
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
62
HEXAGON HEAD BOLT. SCREW LOCK SPRING TO CROSS MEMBER M14X1.5X30
62
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M 14X1.5X35
62
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
64
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
64
NUT SUPPORT TO FRAME
65
NUT HORN TO BRACKET M8
68
NUT HORN TO BRACKET M8
68
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
68
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
71
NUT HORN TO BRACKET M8
74
NUT , Replaced By: N913023006001
77
CLAMP COMPRESSED AIR LINES TO BRACKET AT SUBSTRUCTURE
77
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
77
CLAMP COMPRESSED AIR LINE TO ENGINE CROSS MEMBER,D 216117
77
CLAMP
77
CLAMP HYDRAULIC LINE TO SIDE MEMBER,RB012797
77
CLAMP32 / 20
77
CLAMP COMPRESSED AIR LINE MOUNTING 38/20
77
CLAMP LINE MOUNTING
77
CLAMP DELIVERY AND SUCTION LINES TO FRAME
77
CLAMP LINES TO BRACKET
77
CLAMP20-30
77
CLAMP
77
CLAMP LINE MOUNTING
77
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
77
CLAMP HOSE TO BRACKET 25/20,5 206397
77
CLAMP SUCTION LINE TO CROSS MEMBER
77
CLAMP LINE MOUNTING
79
SPACER TUBE
80
CLAMP COMPRESSED AIR LINE TO ENGINE CROSS MEMBER,D 216117
83
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
83
HEXALOBULAR BOLT CLAMP ON BRACKET M6X30
83
SCREW BRACKET TO COVERING
83
SCREW. HEXAGON HEAD BOLT BATTERY AND ENGINE CABLE HARNESSES TO BRACKET M6X40
83
SCREW BRACKET AND CLAMP M6X20
83
HEXALOBULAR BOLT FASTENING OF WIRING HARNESS AT TRANSMISSION M8X16
83
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
83
SCREW. HEXALOBULAR BOLT BRACKET TO RIGHT FRONT FENDER M8X30
85
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
86
NUT BRACKET TO FIRE WALL
86
NUT HORN TO BRACKET M8
89
CABLE TIE. LOOM TIE CABLE TO ALTERNATOR
92
LOOM TIE LINE MOUNTING
92
LOOM TIE ELECTRIC CABLE MOUNTING
95
WASHER BRACKET TO LEFT SIDE MEMBER
120
V PLUG COMPRESSED-AIR-LINE PLUG-CONNECTION TO M16, M16X1.5 / M16X1.5, VOSS 232
999
999
BRAKE HOSE , Replaced By: A6884208048, +001A0004314831, +001A0019907070
