Поз.
Артикул
Описание
11
SCREW PLUG, FILLINGM14X1,5
11
SCREW PLUG FUEL TANK
14
SEAL RINGTO 000 553 03 05,000 553 18 05,
16
HOSE RETURN, TO BE ADAPTED DURING ASSEMBLY
17
MOLDED HOSE 45-DEGREE ARC 50MM
32
32
35
COOLING WATER PIPEL1200MM
35
38
41
HOSE RADIATOR TO ENGINE 70X82X220MM
41
HOSE RADIATOR TO ENGINE 220 X 70 MM, Replaced By: N000000005015
56
65
ADAPTER FITTING NARROWED STRAIGHT SURFACE 70/65MM
68
69
MOLDED HOSE 90-DEGREE ARC 70MM
69
MOLDED HOSE 90 DEGREES 70MM
70
71
72
LINE
73
SCREW PLUG 3/2-WAY VALVE,CONNECTION:,5 363121
74
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
75
76
77
HOSE38X50X200MM
77
RADIATOR HOSENW38
77
HOSE38X200MM, Replaced By: N000000004995
79
80
HOSED12, 900 MM, TO BE ADAPTED DURING ASSEMBLY
80
HOSE. RADIATOR HOSED12/L850MM, Replaced By: N000000004957
80
HOSE12X21X900MM, TO BE ADAPTED DURING ASSEMBLY
86
HOSE10X19X850MM
86
86
RADIATOR HOSENW10/L850MM, Replaced By: N000000004939
89
HOSE50X62X120, LENGTH AVAILABLE1 000 MM
92
104
HOSE CONNECTION OF OIL FILLER PIPES, ORDER BY THE METER
107
HOSE50X62X250MM
107
HOSE RUBBER 50X250MM, Replaced By: N000000005006
113
MOLDED HOSE ARC REDUCED 90 DEGREES 15/10MM
116
COOLING WATER PIPEL60MM
119
PIPE LINE
122
MOLDED HOSE ENGINE CONNECTION
122
HOSE. RADIATOR HOSENW50/L100MM
122
MOLDED HOSE 90 DEGREES 50MM
999
HOSE. RADIATOR HOSE150LG, UNTIL PRODUCTION BREAKPOINT DATE 05.01.05 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
MOLDED HOSE 45-DEGREE ARC 50MM
999
SLEEVE. ADAPTER FITTING REDUCED 70/65MM
