Поз.
Артикул
Описание
5
CABLE12430MM,OM502LA/GO210
5
CABLE12190MM,OM457LA
5
CABLE , Replaced By: A0002604551
5
CABLE , Replaced By: A0002604351
8
CABLEL13100,OM502LA/GO210
74
RUBBER SEGMENT
77
CLIP
80
RETAINING CLIP
83
CABLE TIE LINE MOUNTING 375X8.4MM
86
BRACKET. CONSOLE AT TRANSMISSION, Replaced By: A6292681536
86
BRACKET. CONSOLE AT TRANSMISSION
93
BALL PINL95MM
95
LEVER
95
LEVER (REVERSING LEVER), Replaced By: A6292601137
96
LEVER
96
LEVER
97
PIN
97
PINL60MM
98
LOCK PLATE CONTROL SHAFT TO CAB
99
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
100
BALL BEARING. GROOVED BALL BEARING INTERMEDIATE LEVER, NOT USED
100
BALL BEARING
100
BALL BEARING
101
NUT HORN TO BRACKET M8
102
SEAL RING
103
SPACER RING
106
THREADED SLEEVEL70MM
107
JOINT
110
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
113
GROMMET AT BRACKET
116
BUSHING
119
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M8X35
122
SCREW BRACKET TO CAB REAR PANEL M 8X20
134
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
134
NUT
146
NUT JOINT TO BRACKET
146
HEXAGON NUT
149
HEXAGON NUT L.H. THREAD M14
152
COTTER PIN
155
NUT REINFORCEMENT TO BRACKET
161
SPACER WASHER AT CONSOLE
167
WASHER
170
WASHER BRACKET TO CAB REAR PANEL
173
SHIFTING CYLINDER
173
SHIFTING CYLINDER , Replaced By: A0012607163, +002A0009973834
174
JOINT
175
BRACKET AT TRANSMISSION, Replaced By: A6292600462
175
BRACKET
176
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
176
SCREWM10X50MM
182
NUT SUPPORT TO FRAME
182
NUT STEERING SUPPORT TO FRAME
182
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
182
HEXAGON NUT BRACKET TO SIDE MEMBER M14 X 1,5
185
HEXAGON HEAD BOLT CONNECTION TO AXLE, NUTS SHAFT-SIDE M14X1,5X50MM
185
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X45
185
HEXAGON HEAD BOLT. SCREW BRACKET TO CONSOLE
188
VALVE. CONTROL VALVE
191
PLATE
194
SHIFT LEVER SHIFTING TRANSFER, R.H.D.
197
BUSHING
205
CONSOLE , Replaced By: A6292681436
205
CONSOLE
208
CLAMPING NUT
214
THREADED PIN , Replaced By: A0002650875
214
THREADED PIN. THREADED ROD
217
JOINT , Replaced By: A0002689089
217
BALL JOINT
220
NUT BRACKET TO SIDE MEMBER M12X1.5
