Поз.
Артикул
Описание
16
MOLDED HOSE ENGINE CONNECTION
17
MOLDED HOSE 45-DEGREE ARC 50MM
32
COOLING WATER PIPE FEED LINE TO TRANSMISSION
35
COOLING WATER PIPE RETURN LINE TO TRANSMISSION
36
LINE. COOLING WATER PIPE
38
COOLING WATER PIPE
39
SCREW PLUG, FILLINGM14X1,5
39
SCREW PLUG FUEL TANK
40
SEALING RING. SEAL RING ENGINE BREATHING
41
HOSE70X82X180MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
41
HOSE. RADIATOR HOSED70/L180MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY, Replaced By: N000000005014
45
HOSE , Replaced By: N000000005003
45
HOSE50X62X120MM
56
LINE RETURN LINE TO TRANSMISSION
65
ADAPTER FITTING NARROWED STRAIGHT SURFACE 70/65MM
68
COOLING WATER PIPEL900MM
69
MOLDED HOSE 90-DEGREE ARC 70MM
70
LINE RETURN LINE TO RADIATOR
72
LINE
76
COOLING WATER PIPE
77
RADIATOR HOSE38X100MM, Replaced By: N000000004992
77
HOSE ,D 209702
85
HOSE. RADIATOR HOSED12/L850MM, Replaced By: N000000004957
85
HOSE12X21X900MM, TO BE ADAPTED DURING ASSEMBLY
86
HOSE HOSE TO EXPANSION TANK 10X1010MM, TO BE ADAPTED DURING ASSEMBLY
92
LINE COOLING WATER FEED LINE AT MOTOR
113
MOLDED HOSE ARC REDUCED 90 DEGREES 15/10MM
116
COOLING WATER PIPED10 70LG
999
TEMPERATURE SENSOR RETARDER TEMPERATURE
999
MOLDED HOSE 45-DEGREE ARC 50MM
999
MOLDED HOSE 45-DEGREE ARC 50MM
999
T-FITTING
999
CONNECTOR
999
GASKET
999
FITTING. CONNECTION PIPE SOCKET
