Поз.
Артикул
Описание
17
TRANSVERSE CONTROL ARM TO AXLE AN TO FRAME
20
LONGITUDINAL CONTROL ARM TO AXLE AN TO FRAME
23
REPAIR KIT DRIVE FLANGE TO A 628 333 19 05
26
SCREW TOP TRAILING ARM ON AXLE BEAM M18 X 1.5 X 60 MM
29
WASHER2X35X50
29
WASHER3X35X50
29
WASHER5X35X50
32
HEXAGON HEAD BOLT. SCREW LONGITUDINAL CONTROL ARM, BOTTOM, ON SUBSTRUCTURE
32
SCREW SHOCK ABSORBER BRACKET TO BEARING BRACKET M18 X 1.5 X 200 MM
35
HEXAGON HEAD BOLT CROSS MEMBER TO SUPPORT M18X1.5X140
38
NUT TRAILER COUPLING TO FRONT CROSS MEMBER M18X1.5
98
HEXAGON HEAD BOLT SUPPORT TO SIDE MEMBER M18X1.5X110
101
PLASTIC PIPE AERATION, ORDER BY THE METER
104
CABLE TIE IONIC EXCHANGER 380X7.8MM
104
CABLE TIE LINE MOUNTING 375X8.4MM
107
TORSION BARD45MM
107
TORSION BAR. STABILIZER , Replaced By: A6293260365
107
TORSION BAR
110
PLATE REAR AXLE
113
CONSOLE STABILIZER TO REAR AXLE
116
BEARING HOUSING. HOUSING
119
BUSHING
122
LINK ROD LEFT AND RIGHT
122
ROD LEFT AND RIGHT, Replaced By: A0003201232
122
LINK , Replaced By: A6283201489
122
LINK , Replaced By: A6283201489
125
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M14X1.5X100
128
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
131
NUT BRACKET TO SIDE MEMBER M12X1.5
134
BEARING BRACKET
155
PLATE
158
BEARING SHELL
161
CLAMP
164
NUT , Replaced By: N913023010002
